纽荷兰零件查询(FD145) - CRAWLER DOZER (N.A. VERSION) (10/98-) (9.481[01]) - HYDRAULIC TILT - OPTIONAL CODE 79107217 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
454 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 14496631 | [3] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 2. | 11106031 | [3] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9 | LEC |
| 3. | 14496731 | [10] | WASHER,M12 x 24 x 2.5 Thk | LEC Superseded by part number: 895-11012 |
| 4. | 11112431 | [9] | SCREW,Hex, M12 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 87015736 |
| 5. | 9824642 | [6] | BOLT,M12 x 1.75 x 42.68mm, Cl 10.9 | BHB Superseded by part number: 626-12035 |
| 6. | 10615879 | [12] | LOCK WASHER,Serr, M12 | LEC Superseded by part number: 10615870 |
| 7. | 11114031 | [1] | BOLT,Hex, M12 x 90, 10.9 | LEC Superseded by part number: 412605 |
| 8. | 79005242 | [6] | WASHER,12.6mm ID x 28mm OD x 7mm Thk | LEC12X28 |
| 9. | 79089841 | [1] | COVER | LEC |
| 10. | 79101129 | [1] | GUARD | LEC |
| 11. | 79101128 | [1] | PLATE | LEC |
| 12. | 76029407 | [1] | GUARD | LEC |
| 13. | 79104750 | [1] | GUARD | LEC- REAR |
| 14. | 79089245 | [2] | FOOTREST | LEC Superseded by part number: 76089488 |
| 15. | 78100065 | [4] | ELBOW | LEC- ASSY |
| 16. | 70923841 | [1] | O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro | LEC Superseded by part number: 9992298 |
| 17. | 76028754 | [2] | FLEXIBLE HOSE | LEC |
| 18. | 79103395 | [1] | FLEXIBLE HOSE | LEC |
| 19. | 79105269 | [1] | FLEXIBLE HOSE | LEC |
