纽荷兰零件查询(FD145) - CRAWLER DOZER (N.A. VERSION) (10/98-) (9.665[07]) - AIR CONDITIONING - CONDENSER - OPTIONAL CODE 76048477 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
559 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76052520 | [1] | CONDENSER | LEC- ASSY SEE TAV.8 Superseded by part number: 76067510 |
| 2. | 76052508 | [1] | ELECTRIC CABLE | LEC |
| 3. | 76052511 | [1] | FLEXIBLE HOSE | LEC |
| 4. | 76052512 | [1] | FLEXIBLE HOSE | LEC |
| 5. | 76047043 | [1] | SUPPORT | LEC Superseded by part number: 87316751 |
| 6. | 76047044 | [1] | BRACKET | LEC- LEFT Superseded by part number: 87316754 |
| 7. | 76052516 | [1] | HYD CONNECTOR | LEC |
| 8. | 76052517 | [1] | HYD CONNECTOR | LEC |
| 9. | 76052522 | [1] | BRACKET | LEC- RIGHT Superseded by part number: 87316758 |
| 10. | 76052523 | [4] | TIE-ROD | LEC Superseded by part number: 87316761 |
| 11. | 76052526 | [2] | PLATE | LEC Superseded by part number: 87316763 |
| 12. | 76052527 | [1] | SHIM | LEC |
| 13. | 79109011 | [4] | PAD | LEC- LOWER |
| 14. | 79109014 | [4] | PAD | LEC- UPPER |
| 15. | 11107231 | [4] | SCREW,Hex, M10 x 50mm, Cl 10.9 | LEC Superseded by part number: 75205092, 43249 |
| 16. | 14496631 | [10] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 17. | 12577221 | [4] | LOCK NUT,M10 x 1.5mm Pitch, 12.30mm High, Cl 10, ZND | LEC10X1,5X12,3 |
| 18. | 76052510 | [1] | HYDRAULIC HOSE | LEC |
| 19. | 76052513 | [1] | FLEXIBLE HOSE | LEC |
| 20. | 79073087 | [1] | CONSOLE | LEC |
| 21. | 79073088 | [1] | BOOT | LEC |
| 22. | 10902031 | [6] | BOLT,Hex, M6 x 12mm, Cl 10.9 | LEC Superseded by part number: 86508616 |
| 23. | 11106231 | [6] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LEC |
| 24. | 11701721 | [6] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 26. | 10115601 | [3] | CLIP,10mm, Coat, P Type | MKT |
| 27. | 10448790 | [1] | CLAMP,30mm, Coat, 9mm Bolt Hole, P Type | LEC30 |
| 28. | 15896221 | [4] | NUT,Hex, M6, 5.20mm High, Cl 10 | ZED Superseded by part number: 86500688 |
| 29. | 76052525 | [1] | KIT | NH- CONDITIONING |
