凯斯零件查询(8540) - CASE IH RECTANGULAR BALER (1/88-12/93) (18) - IMPLEMENT DRIVE LINE, METAL SHIELDS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
741 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
1708205
|
[1] |
UNIVERSAL JOINT
|
HFI
IMPLEMENT HALF ASSEMBLY (sub. 700709010 implement half assembly and 700709011 tractor half assembly)
|
| . . |
700709010
|
[1] |
YOKE
|
CAS
IMPLEMENT HALF ASSEMBLY (see page 18A.)
|
| . . |
700709011
|
[1] |
YOKE
|
CAS
TRACTOR HALF ASSEMBLY (see page 18A.)
|
| 2. |
1708221
|
[1] |
UNIVERSAL JOINT
|
HFI
TRACTOR HALF ASSEMBLY (sub. 700709011 tractor half assembly and 700709010 implement half assembly)
|
| 3. |
HFI1708197
|
[1] |
SHIELD
|
HFI
inner
|
| 4. |
700708364
|
[1] |
KIT
|
CAS
PIN KIT Superseded by part number: 237924A1
|
| 5. |
845198
|
[2] |
KIT
|
CAS
JOURNAL REPAIR KIT Superseded by part number: 84355326
|
| 6. |
77032
|
[1] |
FITTING
|
CAS
1/4-28 zerk Superseded by part number: 88775
|
| 7. |
8803645
|
[1] |
FORK
|
CAS
YOKE, tractor
|
| 8. |
1708239
|
[1] |
SHAFT
|
HFI
YOKE AND SHAFT
|
| 9. |
754242
|
[2] |
NYLON BEARING,52.88 mm ID x 71.32 mm OD x 9.52 mm
|
CAS
NYLON BEARING Superseded by part number: 47941, 579113
|
| 10. |
754291
|
[2] |
THRUST WASHER
|
CAS
THRUST WASHER Superseded by part number: 613437R1
|
| 11. |
754283
|
[2] |
OIL SEAL
|
CAS
SNAP RING Superseded by part number: 56760
|
| 12. |
7813801
|
[1] |
NYLON BEARING
|
CAS
BEARING, center nylon
|
| 13. |
1708247
|
[1] |
SHIELD
|
HFI
outer
|
| 14. |
1708213
|
[1] |
TUBE
|
HFI
YOKE AND TUBE Superseded by part number: 700709012
|
| . . |
700709012
|
[1] |
YOKE
|
CAS
AND TUBE
|
| 15. |
1708189
|
[1] |
FORK
|
HFI
YOKE, implement
|
