凯斯零件查询(8540) - CASE IH RECTANGULAR BALER (1/88-12/93) (17) - GAUGE WHEELS AND WINDGUARD ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
171 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700707969
|
[2] |
WHEEL
|
HFI
gauge Superseded by part number: 700709967, 705574, 84351108
|
| 2. |
6852883
|
[1] |
STRUT
|
HFI
left, gauge wheel
|
| 3. |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
HANGER, windguard
|
| 5. |
6852891
|
[1] |
STRUT
|
HFI
right, gauge wheel
|
| . . |
7701188
|
[8] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 x 1-1/4 hex cap screw grade 5 Superseded by part number: 87670
|
| . . |
7703432
|
[4] |
BOLT,Hex, Serr, 3/8" - 16 x 3/4"
|
CAS
3/8-16 x 3/4 hex flange serrated screw grade 5 Superseded by part number: 255918
|
