凯斯零件查询(8540) - CASE IH RECTANGULAR BALER (1/88-12/93) (17[A]) - TINE PICKUP ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
972 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
6852511
|
[4] |
TUBE
|
HFI
TINE SHAFT
|
| 2. |
6157879
|
[16] |
BEARING HOUSING
|
CAS
bearing Superseded by part number: 706157879
|
| 3. |
6105159
|
[16] |
NYLON BEARING,1.75"
|
IH
BEARING, tine
|
| 4. |
6852479
|
[1] |
ROTOR ASSY.
|
HFI
ROTOR SHAFT, pickup
|
| 5. |
700705612
|
[4] |
CAM FOLLOWER
|
L
BEARING, cam Superseded by part number: 86536275
|
| 6. |
705228
|
[4] |
BRACKET
|
NNA
1/2 external lock washer Superseded by part number: 493-11052, 493-11052, 80705228
|
| 7. |
6867824
|
[56] |
SUPPORT
|
L
tine
|
| 8. |
8045981
|
[56] |
TINE
|
CAS
double
|
| 9. |
702400019
|
[4] |
RETAINER
|
HFI
CLIP
|
| . . |
700013
|
[8] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 round head square neck bolt grade 5
|
| . . |
703132
|
[24] |
SERRATED SCREW
|
CAS
5/16-18 x 3/4 hex flange serrated screw Superseded by part number: 145913
|
| . . |
7701634
|
[56] |
BOLT,Hex, 3/8" - 16 x 2", Gr 5
|
CAS
3/8-16 x 2 hex cap screw grade 5 Superseded by part number: 88436
|
| . . |
7701485
|
[16] |
BOLT,Hex, 1/4" - 20 x 2", Gr 5
|
CAS
1/4-20 x 2 hex cap screw grade 5 Superseded by part number: 87404
|
| . . |
702700045
|
[4] |
LOCK NUT
|
L
1/2-20 spiralock nut
|
| . . |
704619
|
[32] |
SUPPORT
|
NNA
5/16-18 hex center lock nut Superseded by part number: 230-4215
|
| . . |
430-4214
|
[16] |
1/4-20 hex center lock nut
|
|
| . . |
700712011
|
[1] |
BUSHING
|
CAS
1 in., for wheels
|
| . . |
700709967
|
[1] |
BUSHING
|
CAS
3/4 in.
|
