纽荷兰零件查询(FD14E) - CRAWLER DOZER (5.6515[001]) - ROPS CANOPY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
762 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79092338 | [1] | FRAME | LECSTRUCTURE |
| 2. | 79092414 | [1] | ELECTRIC CABLE | LECCABLE |
| 3. | 79092415 | [1] | ELECTRIC CABLE | LECCABLE |
| 4. | 79092416 | [2] | STRAP | LEC |
| 5. | 79092417 | [1] | STRAP | LEC |
| 6. | 79092418 | [2] | STRAP | LEC |
| 7. | 79092419 | [1] | STRAP | LEC |
| 8. | 79092420 | [12] | GASKET | LECSEAL |
| 9. | 13275924 | [20] | SCREW,Pozidriv Pan Hd, M6 x 10mm, Cl 8.8, Full Thd | JES6x1x10 |
| 10. | 14496431 | [20] | WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk | LEC Superseded by part number: 86588450 |
| 11. | 79073816 | [4] | HEADLAMP | LECFLOODLIGHT - ASSEMBLY Superseded by part number: 79073819 |
| 11. | 79094051 | [2] | HEADLAMP | LECFLOODLIGHT - RIGHT ASSEMBLY Superseded by part number: 79093993, 14151690 |
| 11. | 79097886 | [2] | HEADLAMP | LECFLOODLIGHT - LEFT ASSEMBLY Superseded by part number: 79097888 |
| 12. | 79073822 | [1] | SPACER | LEC |
| 13. | 79073823 | [2] | PAD | LECBLOCK |
| 14. | 79073824 | [1] | WASHER | LEC |
| 15. | 79073825 | [1] | NUT | LEC Superseded by part number: 10726711 |
| 16. | 79069460 | [1] | BULB | LECLAMP Superseded by part number: 14151690 |
| 17. | 79080111 | [1] | HEADLAMP LENS | LECREFLECTOR Superseded by part number: 79102125 |
| 18. | 15984334 | [12] | BOLT,Hex, M18 x 1.5 x 50mm, Cl 10.9, Full Thd | BASSCREW 18x1.5x50 Superseded by part number: 87536205 |
| 19. | 79005239 | [12] | WASHER,18.8mm ID x 41mm OD x 8mm Thk | LEC |
