凯斯零件查询(8540) - CASE IH RECTANGULAR BALER (1/88-12/93) (25) - PACKER CRANK ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
672 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
2401544
|
[1] |
CRANK
|
HFI
packer
|
| 2. |
8744062
|
[4] |
SEAL
|
HFI
|
| 3. |
2401570
|
[1] |
FILTER ASSY
|
HFI
PACKER FINGER ASSEMBLY, right (includes retainers no. 2401568)
|
| 4. |
2700105
|
[2] |
BUSHING
|
HFI
BEARING (pair) 2 I.D. x 5" long
|
| 5. |
2401569
|
[1] |
FILTER ASSY
|
HFI
PACKER FINGER ASSEMBLY, left (includes retainers no. 2401568)
|
| 6. |
2401568
|
[4] |
RETAINER
|
HFI
bearing
|
| 7. |
2401575
|
[1] |
LINK ASSY.
|
HFI
LINK, right
|
| 8. |
2401566
|
[2] |
BUSHING
|
HFI
1" O.D. x 1-11/32" long
|
| 9. |
2401567
|
[4] |
SHIM
|
HFI
|
| 10. |
2401562
|
[1] |
LINK ASSY.
|
HFI
LINK, left
|
| 11. |
1700061
|
[2] |
BUSHING
|
HFI
1" I.D. x 1" long
|
| 12. |
1700079
|
[2] |
BUSHING
|
HFI
1" I.D. x 1-1/4 long
|
| . . |
7701683
|
[2] |
BOLT,Hex, 5/8" - 11 x 3", Gr 5
|
CAS
5/8-11 x 3 hex cap screw grade 5 Superseded by part number: 87338
|
| . . |
178-878
|
[4] |
SET SCREW,Hex Soc, 5/16"-18 x 5/16"
|
CAS
5/16-18 x 5/16 cup point hex socket set screw w/nylon patch
|
| . . |
7701634
|
[8] |
BOLT,Hex, 3/8" - 16 x 2", Gr 5
|
CAS
3/8-16 x 2 hex cap screw grade 5 Superseded by part number: 88436
|
