凯斯零件查询(8540) - CASE IH RECTANGULAR BALER (1/88-12/93) (25[A]) - SLIP CLUTCH, PICKUP, ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
617 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
6855282
|
[1] |
PLATE
|
HFI
pressure
|
| 2. |
755421
|
[2] |
FACING
|
HFI
FRICTION DISC, clutch Superseded by part number: 700711022
|
| 3. |
6855274
|
[1] |
DISC
|
HFI
center
|
| 4. |
2401467
|
[1] |
DISC
|
HFI
SPROCKET AND CLUTCH DISC ASSEMBLY, 80-pitch, 32-tooth (includes bushing)
|
| 5. |
8052391
|
[1] |
BRONZE BUSHING
|
CAS
1-3/4 I.D. x 1/2" long
|
| 6. |
58107
|
[6] |
SPRING
|
IH
compression
|
| . . |
873174
|
[6] |
BOLT,Hex, 3/8" - 16 x 3 1/4", Gr 5
|
CAS
3/8-16 x 3-1/4 hex cap screw grade 5
|
| . . |
88902
|
[6] |
NUT,3/8"-16
|
NH
3/8-16 hex center lock nut
|
