凯斯零件查询(8540) - CASE IH RECTANGULAR BALER (1/88-12/93) (33) - STAR WHEEL AND SPACER CAM ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
336 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
51200181
|
[1] |
BUSHING
|
CAS
3/8 I.D. x 3/16" long
|
| 2. |
6853717
|
[1] |
ARM ASSY.
|
HFI
ARM, knotter trip
|
| 3. |
6853741
|
[2] |
STRAP
|
HFI
trip
|
| 4. |
1661234
|
[1] |
CLAMP
|
IH
stop, 3/8-16 thread
|
| 5. |
2401516
|
[1] |
SPACER
|
CAS
ROLLER, hub
|
| 6. |
6853162
|
[2] |
MOUNTING PARTS
|
HFI
MOUNTING BRACKET, star wheel
|
| 7. |
6853147
|
[1] |
SHAFT
|
HFI
star wheel
|
| 8. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 9. |
52241
|
[2] |
WASHER
|
CAS
7/8 x 14 gauge machinery bushing Superseded by part number: 195-2091
|
| 10. |
6530471
|
[2] |
RIM
|
CAS
SHIELD, spacer roller
|
| 11. |
2401515
|
[1] |
CAM
|
HFI
TRACK, cam
|
| 12. |
38-11216
|
[1] |
LOCK PIN,3/16" x 1", Slotted
|
CAS
Pin, 3/16" x 1", Slotted Superseded by part number: 118827
|
| 13. |
700101234
|
[2] |
PLATE
|
HFI
|
| . . |
703249
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 hex cap screw grade 5 Superseded by part number: 88206
|
| . . |
702035
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 x 1-1/4 hex cap screw grade 5
|
| . . |
7703499
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 hex cap screw grade 5 Superseded by part number: 87872
|
| . . |
88902
|
[1] |
NUT,3/8"-16
|
NH
3/8-16 hex center lock nut
|
| . . |
230-4215
|
[2] |
NUT,5/16"-18, GA
|
CAS
5/16-18 hex center lock nut
|
