| 1. |
1662980
|
[1] |
GUIDE
|
HFI
CLUTCH PLATE, pilot
|
| 2. |
700709463
|
[2] |
DISC
|
CAS
FRICTION DISC, clutch Superseded by part number: 700710945
|
| 3. |
51200260
|
[1] |
DISC
|
CAS
PRESSURE PLATE, center
|
| 4. |
1662964
|
[1] |
LARGE PLATE
|
CAS
PRESSURE PLATE
|
| 5. |
6855522
|
[1] |
FITTING
|
HFI
HOUSING AND HUB ASSEMBLY Superseded by part number: 700121567
|
| 6. |
58107
|
[6] |
SPRING
|
IH
compression
|
| 7. |
87569
|
[1] |
LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive
|
PA
1/4-28 x 45deg. zerk
|
| 8. |
6522932
|
[4] |
SHIM
|
CAS
clutch
|
| 9. |
6522916
|
[2] |
PIN
|
CAS
pawl
|
| 10. |
6522924
|
[2] |
CLUTCH
|
CAS
PAWL, overrunning clutch
|
| 11. |
6522940
|
[1] |
SPACER
|
CAS
3/8" long
|
| 12. |
845198
|
[1] |
KIT
|
CAS
JOURNAL REPAIR KIT Superseded by part number: 84355326
|
| 13. |
816025
|
[1] |
YOKE
|
HFI
clamp end
|
| 14. |
7852114
|
[2] |
BUSHING,34.9mm ID x 38.1mm OD x 33.27mm L
|
CAS
1-3/8 I.D. x 1-1/2" long
|
| 15. |
7813298
|
[1] |
YOKE
|
HFI
ASSEMBLY (includes bearing, retainer ring and bushing)
|
| 16. |
7714926
|
[1] |
BALL BEARING,20 mm ID x 42 mm OD x 12 mm
|
CAS
radial Superseded by part number: 84330089
|
| 17. |
7852726
|
[1] |
OIL SEAL
|
CAS
RETAINER RING Superseded by part number: 183442
|
| 18. |
7852817
|
[1] |
BUSHING
|
CAS
1-3/8 I.D. x 1-5/16" long Superseded by part number: 7852114
|
| 19. |
700709603
|
[6] |
WASHER,3/8"
|
CAS
3/4 NPW Superseded by part number: 80702
|
| . . |
7701675
|
[1] |
BOLT,Hex, 1/2" - 13 x 2", Gr 5
|
CAS
1/2-13 x 2 hex cap screw grade 5 Superseded by part number: 9706716
|
| . . |
7772767
|
[6] |
SCREW,Hex, 3/8" - 16 x 3 1/2", Gr 5
|
CAS
3/8-16 x 3-1/2 hex cap screw grade 5 Superseded by part number: 88959
|
| . . |
7702038
|
[1] |
SCREW,Hex, 1/2" - 13 x 3", Gr 5
|
CAS
1/2-13 x 3 hex cap screw grade 5 Superseded by part number: 87339
|
| . . |
704122
|
[6] |
NUT
|
CAS
3/8-16 heavy hex stop nut Superseded by part number: 131-463
|
