凯斯零件查询(8540) - CASE IH RECTANGULAR BALER (1/88-12/93) (38) - WIRE TWISTER PLATFORM Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
880 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8802258
|
[1] |
TWISTER
|
HFI
FRAME, twister
|
| 2. |
8806697
|
[2] |
ROD
|
HFI
wire deflector
|
| 3. |
8802241
|
[2] |
SHAFT
|
HFI
twister
|
| 4. |
7813165
|
[2] |
TWISTER
|
CAS
WIRE TIE TWISTER
|
| 5. |
52183
|
[1] |
BUSHING
|
CAS
3/4 x 18 gauge machinery bushing Superseded by part number: Z52183
|
| 6. |
6859383
|
[2] |
PIN
|
HFI
|
| 7. |
740787
|
[6] |
BRONZE BUSHING
|
CAS
3/4 I.D. x 1" long
|
| 8. |
6859375
|
[2] |
ROLLER
|
HFI
3-15/16" long
|
| 9. |
763482
|
[2] |
PIN
|
HFI
3/16 x 1-1/8 slotted spring pin
|
| 10. |
8806689
|
[1] |
SHAFT
|
HFI
cam
|
| 11. |
7813157
|
[1] |
CAM
|
CAS
|
| 12. |
63107
|
[4] |
LOCK PIN,1/4" x 1 1/2", Slotted
|
CAS
PIN, LOCK, 1/4" x 1 1/2", Slotted Superseded by part number: 87406
|
| 13. |
748426
|
[2] |
LEDGER PLATE
|
HFI
|
| 14. |
7813207
|
[4] |
SPACER
|
HFI
lower
|
| 15. |
7813215
|
[4] |
TOW BAR
|
HFI
TONGUE, wire holder
|
| 16. |
7813181
|
[4] |
SPACER
|
HFI
upper
|
| 17. |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
3/4 x 14 gauge machinery bushing
|
| 18. |
851931
|
[2] |
SPROCKET ASSY.
|
CAS
SPROCKET, 40-P, 15-tooth
|
| 19. |
7813272
|
[2] |
CUTTER
|
HFI
wire
|
| 20. |
2401582
|
[2] |
GUIDE
|
HFI
WIRE GUIDE
|
| 21. |
8802381
|
[1] |
BAR
|
HFI
SHUTTLE BAR
|
| 22. |
77248
|
[3] |
FITTING
|
HFI
1/4-28 zerk, taper thread Superseded by part number: 86547835
|
| 23. |
7813173
|
[1] |
HUB ASSY.
|
HFI
HUB, cam
|
| 24. |
51169
|
[1] |
BEARING
|
HFI
cam follower Superseded by part number: R33825
|
| 25. |
700101227
|
[2] |
GUIDE
|
HFI
wire
|
| 26. |
704197
|
[2] |
NUT
|
CAS
3/8-24 hex jam nut Superseded by part number: 425-156, 425-156, NLS
|
| . . |
7703499
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 hex cap screw grade 5 Superseded by part number: 87872
|
| . . |
703579
|
[4] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5, Full Thd
|
CAS
5/16-18 x 1 hex cap screw grade 5
|
| . . |
7884729
|
[8] |
HARDWARE
|
HFI
5/16-24 x 1-3/4 hex cap screw grade 5 Superseded by part number: 80280387
|
| . . |
72694
|
[2] |
BOLT
|
HFI
3/8-24 x 2 hex cap screw grade 5 Superseded by part number: 87753
|
| . . |
7884711
|
[2] |
HEX SOC SCREW,5/16" - 24 x 1/2"
|
HFI
5/16-24 x 1/2 hex socket head cap screw grade 5 Superseded by part number: 62-58
|
| . . |
704536
|
[8] |
LOCK NUT
|
HFI
5/16-24 hex center lock nut Superseded by part number: 230-4715
|
