凯斯零件查询(8540) - CASE IH RECTANGULAR BALER (1/88-12/93) (39) - LEFT AND RIGHT WIRE BOX ASSEMBLIES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
594 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
6859425
|
[2] |
PANEL
|
HFI
side
|
| 2. |
6859466
|
[2] |
PANEL
|
HFI
outer
|
| 3. |
6859441
|
[1] |
BASE
|
HFI
|
| 4. |
6859433
|
[2] |
PANEL
|
HFI
side
|
| 5. |
6859458
|
[2] |
PANEL
|
HFI
inner
|
| 6. |
6859474
|
[1] |
CHANNEL
|
HFI
wire box
|
| 7. |
700100006
|
[1] |
GUARD
|
HFI
wire
|
| 8. |
6560346
|
[1] |
SPACER
|
HFI
5/8 O.D. x 13/32" long
|
| 9. |
700101200
|
[4] |
ANGLE
|
HFI
divider
|
| 10. |
6859417
|
[2] |
BOX
|
HFI
WIRE BOX ASSEMBLY
|
| . . |
7770282
|
[28] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1/2", Gr 5
|
CAS
5/16-18 x 1/2 round head square neck bolt grade 5 Superseded by part number: 280616
|
| . . |
703579
|
[1] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5, Full Thd
|
CAS
5/16-18 x 1 hex cap screw grade 5
|
| . . |
703249
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 hex cap screw grade 5 Superseded by part number: 88206
|
