凯斯零件查询(8540) - CASE IH RECTANGULAR BALER (1/88-12/93) (42) - BALE CHUTE, QUARTER TURN, KIT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
936 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
HK50391
|
[1] |
EXTENSION
|
ATT
BALE CHUTE (quarter turn) KIT COMPLETE
|
| 1. |
700108714
|
[1] |
STOP
|
CAS
- extension
|
| 2. |
700112628
|
[1] |
CHUTE ASSY.
|
CAS
CHUTE - bale, left
|
| 3. |
6450183
|
[2] |
CHAIN (AG)
|
CAS
CHAIN - chute, left
|
| 4. |
6856538
|
[1] |
BRACKET
|
CAS
- chain, angled
|
| 5. |
6859102
|
[1] |
BRACKET
|
CAS
- chain
|
| 6. |
7475495
|
[2] |
SPACER
|
HFI
|
| 7. |
6856512
|
[2] |
SPACER
|
CAS
(.551" long)
|
| 8. |
6856520
|
[4] |
ANGLE
|
CAS
- guide
|
| 9. |
700112635
|
[1] |
CHUTE (DOWNWARD)
|
CAS
CHUTE - bale, right
|
| . . |
700054
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
3/8-16 x 1-1/4 RHSNB Superseded by part number: 86508773
|
| . . |
700047
|
[3] |
BOLT
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
703249
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 hex cap screw grade 5 Superseded by part number: 88206
|
| . . |
7883325
|
[8] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
7771751
|
[1] |
BOLT,Hex, 5/16" - 18 x 3", Gr 5
|
CAS
5/16-18 x 3 C Superseded by part number: 88731
|
| . . |
88902
|
[6] |
NUT,3/8"-16
|
NH
3/8-16 HCLN
|
