凯斯零件查询(8540) - CASE IH RECTANGULAR BALER (1/88-12/93) (48) - THROWER BELTS, SHIELDS AND CHUTE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
341 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
HK4600BT
|
[1] |
BALE THROWER KIT COMPLETE
|
|
| 1. |
S120261
|
[2] |
PIN
|
CAS
.148 x 2-3/4 hair pin cotter
|
| 2. |
1662543
|
[2] |
CHAIN (AG)
|
CAS
CHAIN
|
| 3. |
1662527
|
[1] |
ROD
|
CAS
CHUTE ROD
|
| 4. |
1662402
|
[1] |
CHUTE ASSY.
|
HFI
UPPER CHUTE
|
| 5. |
329920
|
[1] |
SCREW
|
HFI
CHUTE PIN
|
| 6. |
1662360
|
[1] |
CHUTE ASSY.
|
HFI
LOWER CHUTE
|
| 7. |
1662519
|
[2] |
SHIELD
|
CAS
BALE CHUTE SHIELD
|
| 8. |
1662535
|
[2] |
PIN
|
CAS
SHIELD ROD
|
| 9. |
7855265
|
[1] |
V-BELT
|
HFI
|
| 10. |
1662659
|
[1] |
ANGLE
|
HFI
LOWER SHIELD SUPPORT ANGLE
|
| 11. |
1662436
|
[1] |
BRACKET
|
HFI
SPRING AND SHIELD MOUNTING BRACKET
|
| 12. |
263350
|
[1] |
BOLT
|
CAS
DRAWBOLT Superseded by part number: 51200342
|
| 13. |
758102
|
[1] |
SPRING
|
CAS
|
| 14. |
1662683
|
[1] |
SHIELD
|
HFI
|
| 15. |
1662675
|
[1] |
BRACKET
|
HFI
SHIELD SUPPORT BRACKET
|
| 16. |
6840847
|
[2] |
BUSHING
|
CAS
(.541 I.D. x .591 long)
|
| 17. |
828194
|
[2] |
BELT,12.0" W
|
HFI
|
| 18. |
828186
|
[2] |
PIN
|
CAS
Superseded by part number: 700711329
|
| 19. |
6612030
|
[1] |
GROMMET
|
HFI
trim
|
| . . |
7883325
|
[8] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 hex washer head machine screw grade 5 Superseded by part number: 121-115
|
| . . |
700047
|
[2] |
BOLT
|
CAS
3/8-16 x 1 round head square neck bolt grade 5 Superseded by part number: 80280503
|
| . . |
7700016
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2 1/2", Gr 5
|
CAS
3/8-16 x 2-1/2 round head square neck bolt grade 5 Superseded by part number: 280744
|
| . . |
701235
|
[2] |
BOLT,1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 x 1-1/2 hex cap screw grade 5
|
