纽荷兰零件查询(FD14E) - CRAWLER DOZER (95.6520[013]) - ROPS CAB-WINDSHIELD WIPER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
253 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79094763 | [1] | SMALL ELECTRIC MOTOR | LECSWING MOTOREDUCTION |
| 2. | 79094764 | [1] | PIN | LEC- ASSEMBLY |
| 3. | 79097239 | [1] | LINK CONROD | LECLINK ROD |
| 4. | 79066424 | [1] | LEVER | LEC |
| 5. | 79094632 | [1] | ARM | LEC |
| 6. | 79073547 | [1] | WIPER BLADE,700mm L | LECBRUSH |
| 7. | 16100821 | [1] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 9. | 79045384 | [2] | PROTECTION CAP | LECBOOT |
| 10. | 16102621 | [2] | THIN NUT,Thin, M20 x 1.5, Cl 04 | LEC20x1,5x8 |
| 11. | 79044651 | [2] | SPACER | LEC |
| 12. | 10284585 | [2] | GASKET | MKT20,2x26 Superseded by part number: 98429280 |
| 13. | 79095755 | [1] | BRACKET | LEC- RIGHT |
| 13. | 79095756 | [1] | BRACKET | LEC- LEFT |
| 14. | 10450190 | [6] | CLAMP,10mm, Coat, 9mm Bolt Hole, P Type | JESCLIP 66x9 Superseded by part number: |
| 15. | 79097503 | [6] | WASHER | LEC Superseded by part number: 76067146 |
| 16. | 79097502 | [4] | SPACER | LEC |
| 17. | 14496531 | [12] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC8,15x17 Superseded by part number: 86624184 |
| 18. | 10902231 | [6] | SCREW,Hex, M6 x 16mm, Cl 10.9 | LECBOLT, Hex, M6 x 16, 10.9 Superseded by part number: 86639037 |
| 19. | 16043031 | [6] | BOLT,Hex, M8 x 12mm, Cl 10.9, Full Thd | LEC Superseded by part number: 43231 |
| 19. | 16043231 | [6] | SCREW,Hex, M8 x 16mm, Cl 10.9, Full Thd | LECSCREW 8x1,25x16 |
| 20. | 12643701 | [6] | WASHER,6.15mm ID x 18mm OD x 1.5mm Thk | LEC Superseded by part number: 12643704 |
