HK50391
|
[1] |
EXTENSION
|
ATT
BALE CHUTE QUARTER TURN KIT COMPLETE
|
| 1. |
495-21044
|
[10] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 2. |
413-616
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 3. |
230-4216
|
[6] |
LOCK NUT,3/8"-16, GA
|
CAS
3/8-16 HCLN Superseded by part number: 87039402
|
| 4. |
6450183
|
[1] |
CHAIN (AG)
|
CAS
CHAIN - chute, left, 36" long
|
| 5. |
700112628
|
[1] |
CHUTE ASSY.
|
CAS
CHUTE WA - bale, left
|
| 6. |
700108714
|
[1] |
STOP
|
CAS
- extension
|
| 7. |
413-548
|
[1] |
BOLT,Hex, 5/16" - 18 x 3", Gr 5
|
CAS
Superseded by part number: 88731
|
| 8. |
492-11031
|
[1] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 9. |
425-105
|
[1] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 10. |
6856538
|
[1] |
BRACKET
|
CAS
- chain, left
|
| 11. |
433-620
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 12. |
434-616
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 13. |
6475495
|
[2] |
BUSHING
|
CAS
SPACER
|
| 14. |
6859102
|
[1] |
BRACKET
|
CAS
- chain, right
|
| 15. |
6559876
|
[1] |
CHAIN (AG)
|
CAS
CHAIN - chute, right, 25" long
|
| 16. |
6856512
|
[2] |
SPACER
|
CAS
|
| 17. |
6856520
|
[4] |
ANGLE
|
CAS
- guide
|
| 18. |
121-115
|
[8] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 19. |
231-5145
|
[8] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 20. |
700112635
|
[1] |
CHUTE (DOWNWARD)
|
CAS
CHUTE WA - bale, right
|
