HK50392
|
[1] |
HITCH ASSY
|
CAS
WAGON HITCH KIT COMPLETE
|
| 1. |
432-816
|
[1] |
COTTER PIN,1/8" x 1"
|
CAS
1/8" x 1" Superseded by part number: 80755
|
| 2. |
700112625
|
[1] |
TUBE,60.32 mm OD, 1580 mm Length
|
CAS
- hitch
|
| 3. |
409-7820
|
[2] |
BOLT,Hex Flg, 1/2" - 13 x 1 1/4", Spcl
|
CAS
Superseded by part number: 84209
|
| 4. |
80679
|
[2] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 5. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 6. |
700122609
|
[1] |
STRUT
|
CAS
- left
|
| 7. |
413-1032
|
[2] |
BOLT,Hex, 5/8" - 11 x 2", Gr 5
|
CAS
C Hex, 5/8"-11 x 2", G5 Superseded by part number: 86505999
|
| 8. |
396-21066
|
[4] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 9. |
492-11062
|
[3] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 10. |
425-1010
|
[3] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 11. |
413-1028
|
[1] |
BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 5
|
CAS
5/8-11 X 1-3/4 C Superseded by part number: 9627896
|
| 12. |
700122610
|
[1] |
STRUT
|
CAS
- right
|
| 13. |
700112619
|
[1] |
SUPPORT
|
CAS
MOUNTING - support, rear
|
| 14. |
700112618
|
[1] |
PIPE
|
CAS
TUBE - outer, front
|
| 15. |
111-360
|
[4] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 3/4", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 3/4", G5 Superseded by part number: 280430
|
| 16. |
492-11038
|
[4] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 17. |
425-106
|
[4] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 18. |
6557565
|
[1] |
PIN
|
CAS
|
