HK40445
|
[1] |
LIGHT
|
ATT
FIELD LIGHT KIT COMPLETE
|
| 1. |
515-2363
|
[7] |
CLAMP,M6.3, Insul, 3/8" Bolt
|
CAS
- line Superseded by part number: 675162
|
| 2. |
700704526
|
[1] |
WIRE HARNESS
|
CAS
HARNESS - wiring, rear
|
| 3. |
409-7612
|
[1] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HFSS Superseded by part number: 72187187, 255918
|
| 4. |
231-5146
|
[2] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 5. |
386170C1
|
[1] |
CABLE TIE,.30" x 27 1/2"
|
IH
TIE - cable Superseded by part number: 435437A1
|
| 6. |
413-616
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 7. |
492-11038
|
[4] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 8. |
425-106
|
[4] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 9. |
700116986
|
[1] |
CLAMP
|
CAS
- mounting
|
| 10. |
9426333
|
[1] |
FUSE,15 Amp, Type 3AG
|
IH
- 15 amp Superseded by part number: 590420
|
| 11. |
2700179
|
[1] |
ELECTRICAL WIRE
|
CAS
HARNESS - wiring
|
| 12. |
700116985
|
[1] |
STRAP
|
CAS
- mounting
|
| 13. |
CAS41624
|
[3] |
LAMP
|
CAS
|
| 14. |
700704525
|
[1] |
WIRE HARNESS
|
CAS
HARNESS -, Serial Range: wiring,-switch
|
| 15. |
409-7512
|
[1] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Hex Flg, 5/16-18 x 3/4", Serr Superseded by part number: 145913, 72187186
|
| 16. |
231-5145
|
[1] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 17. |
80041137
|
[1] |
|
FRAME
|
| 18. |
700108708
|
[2] |
STRAP
|
CAS
- bracket
|
| 19. |
433-620
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 20. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 21. |
L18337
|
[2] |
CABLE TIE,9.95"-12.1" lg
|
CAS
STRAP - tie, 15 inch, nylon Superseded by part number: 529070
|
| 22. |
111-360
|
[1] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 3/4", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 3/4", G5 Superseded by part number: 280430
|
