纽荷兰零件查询(FD14E) - CRAWLER DOZER (1.2000[006]) - UNIT TORQUE CONVERTER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
694 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 565153 | [1] | GASKET | MKT Superseded by part number: 1905922 |
| 2. | 565154 | [1] | RING | MOD |
| 3. | 79066184 | [1] | HYDRAULIC PUMP | LECPUMP - ASSEMBLY SEE TAV. 10 Superseded by part number: 76029031 |
| 4. | 591794 | [1] | CHANNEL | LEC |
| 5. | 4526899 | [1] | COUPLING RING | BRERING |
| 6. | 4526900 | [1] | SNAP RING | BRESNAP RING |
| 9. | 14496431 | [4] | WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk | LEC Superseded by part number: 86588450 |
| 11. | 11067476 | [1] | SNAP RING,M26, Ext | LECRing, Retaining, M26, Ext |
| 12. | 20685450 | [2] | BALL BEARING,30 mm ID x 62 mm OD x 16 mm | TTFBEARING 30x62 Superseded by part number: 75224976, 210064, 700803262 |
| 13. | 79009557 | [1] | SPACER | LEC |
| 14. | 79010926 | [1] | SHAFT | LEC |
| 15. | 79010927 | [1] | GEAR | LEC |
| 10. | 10903024 | [4] | BOLT,Hex, M6 x 35mm, Cl 8.8 | TTFSCREW, Hex, M6 x 35, 8.8 Superseded by part number: 16604024 |
