纽荷兰零件查询(FD14E) - CRAWLER DOZER (1.2000[010]) - UNIT TORQUE CONVERTER-STEERING-CONVERT SCAVENGE PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
650 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 10298360 | [4] | SEALING WASHER,M10.2 x 16 x 1, Copper | LECGASKET 10,2x16 Superseded by part number: 4858606 |
| 2. | 10571879 | [4] | LOCK WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk | TTFWASHER, LOCK, M10 Superseded by part number: |
| 3. | 11058676 | [1] | SNAP RING,M28, Int | LECRING, SNAP, (30.1 OD x 1.2 Thk) M28, Int Superseded by part number: 301642, 75210849 |
| 4. | 12164721 | [4] | NUT,M10 x 1.25, Cl 10 | TTF10x1,25x8 |
| 5. | 14458080 | [1] | O-RING,0.103" Thk x 1.11" ID, -122, Cl 5, 75 Duro | MKT0-RING 2,62x28,24 Superseded by part number: 14458081 |
| 6. | 14460380 | [4] | O-RING,0.103" Thk x 2.55" ID, -145, Cl 5, 75 Duro | MKT0-RING 2,62x64,77 Superseded by part number: 9672457 |
| 7. | 15973134 | [4] | SCREW,M10 x 1.25 x 180mm, Cl 10.9 | LEC10x1,25x180 Superseded by part number: 15973131 |
| 8. | 79069701 | [1] | KIT | LEC |
