| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 001(A). | 1811002463 | [1] | STARTER ASM | DENSO 24V-5.5KW SEE FIG-NO 0-65 FOR COMPONENT. |
| 001(B). | 1811002941 | [1] | STARTER ASM | NIKKO 24V-7.4KW SEE FIG-NO 0-65 FOR COMPONENT. |
| 001(B). | 1811003205 | [1] | STARTER ASM | MITSUBISHI 24V-5.5KW SEE FIG-NO 0-65 FOR COMPONENT. |
| 002. | 1812004821 | [1] | GENERATOR ASM | DENSO 24V-40A SEE FIG-NO 0-66 FOR COMPONENT. |
| 006. | 9091605140 | [2] | WASHER; PL,STARTER | A |
| 006. | 0916105140 | [2] | WASHER; PL,STARTER | |
| 007. | 9991104140 | [2] | NUT; STARTER | A |
| 007. | 0911105140 | [2] | NUT; STARTER | |
| 016. | 9098012030 | [1] | BOLT; GEN | M14X128 |
| 017. | 9091607140 | [1] | WASHER; PL,GEN | A |
| 017. | 9091647140 | [1] | WASHER; PL,GEN | A |
| 017. | 0916147140 | [1] | WASHER; PL,GEN | |
| 019. | 1197110380 | [1] | BRACKET; GEN | |
| 023. | 0911501140 | [1] | NUT; GEN | |
| 026. | 0168060750 | [2] | BOLT; GEN BRKT | M10X75 |
| 026. | 0501510450 | [1] | BOLT; GEN BRKT | M10X45W/LK&PL WASHER |
| 026. | 0281810450 | [1] | BOLT; GEN BRKT | A M10X45 FLANGE |
| 026. | 0281810700 | [2] | BOLT; GEN BRKT | A M10X70 FLANGE |
| 026. | 0281510450 | [1] | BOLT; GEN BRKT | M10X45 FLANGE |
| 026. | 0281510700 | [2] | BOLT; GEN BRKT | M10X70 FLANGE |
| 056(A). | 1824100913 | [1] | SWITCH; OIL PRESSURE WARNING | |
| 056(A). | 1824101900 | [1] | SWITCH; OIL PRESSURE WARNING | C |
| 056(C). | 1824102001 | [1] | SWITCH; OIL PRESSURE WARNING | |
| 056(D). | 8973243720 | [1] | SWITCH; OIL PRESSURE WARNING | |
| 089. | 8971256001 | [1] | SWITCH; OVER HEAT WARNING | |
| 100(A). | 1097091780 | [1] | CLIP; HARNESS | |
| 108. | 1831610330 | [1] | SWITCH; THERMO | |
| 247. | 9091605100 | [2] | WASHER; PL,BRKT,GEN | |
| 248. | 9091505100 | [2] | WASHER; LK,BRKT,GEN | |
| 292. | 9091505140 | [2] | WASHER; LK,STARTER | A |
| 292. | 0915105140 | [2] | WASHER; LK,STARTER | |
| 293. | 1826502390 | [1] | CABLE; STARTER EARTH | |
| 420. | 1826992390 | [1] | BRACKET; HARNESS | |
| 424. | 1825530440 | [1] | RELAY; SAFETY,STARTER | HITACHI |
| 424. | 1825530391 | [1] | RELAY; SAFETY,STARTER | NIKKO |
| 696. | 1825503100 | [1] | CONTROL UNIT |
