凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (2-10) - CLUTCH ASSEMBLY (S.N. CFH0045101 THRU CFH0045225) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
706 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
7772767
|
[6] |
SCREW,Hex, 3/8" - 16 x 3 1/2", Gr 5
|
CAS
3/8-16 X 3-1/2 C Superseded by part number: 88959
|
| 2. |
495-21044
|
[6] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 3. |
231-1406
|
[6] |
LOCK NUT,3/8"-16, GB
|
CAS
3/8 LIGHT HEX STOP NUT
|
| 4. |
700112497
|
[1] |
PLATE
|
CAS
WA - mounting clutch (Includes item 9)
|
| 5. |
700710945
|
[2] |
CLUTCH PLATE,126.75mm ID x 203.2mm OD x 3.18mm Thk
|
L
DISC - clutch
|
| 6. |
700112494
|
[1] |
DISC
|
CAS
ROTOR WA - clutch
|
| 7. |
1662964
|
[1] |
LARGE PLATE
|
CAS
PLATE - outer, pressure
|
| 8. |
58107
|
[6] |
SPRING
|
IH
- compression
|
| 9. |
852749
|
[1] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
