| 1. |
495-21056
|
[1] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 2. |
95-81101
|
[2] |
WASHER,0.52" ID x 0.88" OD x 0.07" Thk
|
CAS
1/2 X 14 GA. NRMB
|
| 3. |
565442R91
|
[1] |
SPROCKET
|
IH
- idler, 50B17 tooth Superseded by part number: 87302107
|
| 4. |
761379
|
[1] |
BUCKET TOOTH KEY
|
IH
5/16 X 5/16 X 1-3/4 GIB KEY Superseded by part number: Q3930
|
| 5. |
700119343
|
[1] |
PINION
|
L
SPROCKET WA - 50B44 tooth
|
| 6. |
T27207
|
[2] |
FLANGED BEARING
|
CAS
FLANGE - bearing Superseded by part number: 617863R1
|
| 7. |
571588R92
|
[1] |
BALL BEARING,1.3755" ID x 72 mm OD x 1"
|
IH
- spherical Superseded by part number: 47066
|
| 8. |
433-512
|
[29] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 9. |
492-11031
|
[29] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 10. |
425-105
|
[29] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 11. |
700112389
|
[1] |
SHIELD
|
CAS
WRAPPER - end
|
| 12. |
700112379
|
[27] |
GUARD
|
IH
WRAPPER - tine
|
| 13. |
409-7512
|
[28] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Hex Flg, 5/16-18 x 3/4", Serr Superseded by part number: 145913, 72187186
|
| 14. |
434-616
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 15. |
492-11038
|
[3] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 16. |
425-106
|
[3] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 17. |
700119344
|
[1] |
FUNNEL
|
CAS
FRAME WA - pickup
|
| 18. |
433-836
|
[1] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 2 1/4", Gr 5
|
CAS
1/2-13 X 2-1/4 RHSNB Superseded by part number: 280504
|
| 19. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 20. |
425-108
|
[1] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 21. |
700127966
|
[1] |
STOP
|
CAS
- idler
|
