凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (7-02) - HITCH, JACK AND CHAIN ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
545 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
495-11106
|
[4] |
WASHER,1", SAE
|
CAS
Superseded by part number: 87367
|
| 2. |
700108808
|
[1] |
SCREW
|
HFI
1-8 X 5-1/2 C, special
|
| 3. |
413-1056
|
[1] |
BOLT,Hex, 5/8" - 11 x 3-1/2", Gr 5
|
CAS
Superseded by part number: 280119
|
| 4. |
230-41110
|
[1] |
LOCK NUT,5/8"-11, GA
|
CAS
5/8-11 HTLN GR/B Superseded by part number: 85700693
|
| 5. |
148558C1
|
[1] |
CLEVIS
|
IH
- safety, chain Superseded by part number: 1279163C1
|
| 6. |
432-1232
|
[1] |
COTTER PIN,3/16" OD x 2" L
|
CAS
3/16" x 2" Superseded by part number: 87400
|
| 7. |
425-1216
|
[1] |
SLOTTED NUT,Hex, 1"-8, G5
|
CAS
Superseded by part number: 87343900
|
| 8. |
192-171
|
[1] |
LOCK WASHER,1"
|
CAS
WASHER, LOCK, 1" Superseded by part number: 92-21100
|
| 9. |
700709409
|
[1] |
LINK CHAIN
|
CAS
PIN AND CHAIN ASSEMBLY
|
| 10. |
700705598
|
[1] |
CHAIN (CE)
|
CAS
SAFETY - chain
|
| 11. |
D51609
|
[1] |
BALL JOINT
|
CAS
BEARING - tongue
|
| 12. |
6227391
|
[1] |
TUBE,2" OD, 1.88" Length
|
CAS
- wa
|
| 13. |
700702059
|
[1] |
KIT
|
CAS
GEAR SET Superseded by part number: 86590811
|
| 14. |
700709385
|
[1] |
JACK
|
IH
|
| 15. |
700702060
|
[1] |
CRANKED HANDLE
|
CAS
CRANK KIT
|
