凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (7-04) - WHEEL AND HUB ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
228 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T52730
|
[5] |
WHEEL BOLT
|
IH
9/16-18 X 1-1/8 WHEEL BOLT Superseded by part number: 86628557
|
| 2. |
700707949
|
[1] |
RIM
|
CAS
WHEEL - 14 X 8 INCH
|
| . . |
700710278
|
[1] |
WHEEL
|
CAS
- 15 X 10 INCH
|
| 3. |
T27814
|
[1] |
CAP
|
CAS
- hub Superseded by part number: 200734
|
| 4. |
704346
|
[1] |
BRACKET
|
IH
1-14 SLOTTED HEX JAM NUT Superseded by part number: 129-270, 129-270, NLS
|
| 5. |
E13994
|
[1] |
BEARING,25.4mm ID
|
CAS
CONE - bearing, outer
|
| 6. |
50104
|
[1] |
BEARING CUP,50.01mm OD
|
CAS
CUP - bearing, outer
|
| 7. |
618024R1
|
[1] |
BEARING CUP,65.113mm OD x 13.97mm W
|
IH
Inner Superseded by part number: 86516467
|
| 8. |
618023R91
|
[1] |
BEARING ASSY,34.93mm ID x 18.2mm W
|
IH
CONE - bearing, inner
|
| 9. |
844571
|
[1] |
SEAL
|
L
- grease Superseded by part number: 678620
|
| 10. |
700119247
|
[1] |
SHAFT
|
CAS
SPINDLE
|
| 11. |
6280788
|
[1] |
HUB
|
L
(Includes Items 6 and 7)
|
| 12. |
432-824
|
[1] |
COTTER PIN,1/8" x 1 1/2"
|
CAS
PIN, SPLIT (COTTER), 1/8" x 1-1/2" Superseded by part number: 80708
|
| 13. |
827402
|
[1] |
VALVE
|
IH
STEM - valve (Used With 700707949 Wheel)
|
| . . |
A38261
|
[1] |
VALVE
|
CAS
STEM - valve (Used With 700710278 Wheel) Superseded by part number: 196033
|
