凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (7-06) - BALE CHAMBER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
890 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
434-616
|
[19] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 2. |
492-11038
|
[15] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 3. |
425-106
|
[15] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 4. |
700119273
|
[1] |
CHANNEL
|
CAS
- side, left Superseded by part number: 700136634
|
| 5. |
837971
|
[2] |
CASTING
|
CAS
RESISTOR - bar, hay
|
| 6. |
700119272
|
[2] |
RAIL
|
CAS
- compression
|
| 7. |
496-11041
|
[11] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 8. |
232-5316
|
[4] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 9. |
433-820
|
[16] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 10. |
80679
|
[16] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 11. |
425-108
|
[16] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 12. |
700108401
|
[4] |
SUPPORT
|
CAS
SPREADER - chamber
|
| 13. |
700119274
|
[1] |
CHANNEL
|
CAS
- side, right Superseded by part number: 700136635
|
| 14. |
7020597
|
[1] |
BRACKET
|
CAS
STAKE - mounting, SMV (EXTRA)
|
| 15. |
7020589
|
[1] |
EMBLEM
|
CAS
- SMV (EXTRA) Superseded by part number: 86547710
|
| 16. |
470-11012
|
[2] |
SCREW,Pan HD, #10 - 24 x 3/4"
|
CAS
|
| 17. |
492-11010
|
[2] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 18. |
225-14110
|
[2] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 19. |
A59457
|
[1] |
BRACKET
|
CAS
SOCKET - lamp bracket Superseded by part number: 847590
|
