纽荷兰零件查询(FD14E) - CRAWLER DOZER (1.2770[008]) - REAR TRANSMISSION-STEERING BRAKE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
795 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 599296 | [2] | SPRING | LEC |
| 2. | 599299 | [4] | PIN,10mm OD x 57mm L | LEC |
| 3. | 599300 | [2] | YOKE | LEC- UPPER |
| 4. | 599301 | [2] | YOKE | LEC- LOWER |
| 5. | 599302 | [2] | | LEC Superseded by part number: BER599302, BER599302, LEC599302 |
| 6. | 599303 | [2] | SUPPORT | LEC |
| 7. | 599307 | [2] | PIN,24mm OD x 96mm L | LEC |
| 8. | 599308 | [2] | LEVER | LECTIEROD |
| 9. | 599309 | [2] | BRACKET | LEC |
| 10. | 4958134 | [2] | PIN | LEC- UPPER |
| 11. | 4958201 | [4] | RETAINING WIRE | LECPLUNGER |
| 12. | 4983613 | [2] | PIN,24mm OD x 96mm L | LEC |
| 13. | 14496531 | [2] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC8,15x17 Superseded by part number: 86624184 |
| 14. | 10733601 | [8] | COTTER PIN,M3.2 x 22 | TTF2,7x31,6 |
| 15. | 10734201 | [2] | COTTER PIN,M2 x 12 | TTF1,7x18,5 Superseded by part number: |
| 16. | 84021874 | [4] | SNAP RING,M18, Ext | NH16,5x1,2 |
| 17. | 11255934 | [8] | BOLT,Hex, M14 x 1.5 x 40, 10.9, Full Thd | LECSCREW Superseded by part number: 11255931 |
| 18. | 13852540 | [100] | RIVET,6mm OD x 12mm L | LEC6x12 |
| 19. | 14198811 | [2] | LOCKING PLATE | LECLOCKPLATE 10,4x20 |
| 20. | 15970534 | [2] | BOLT,Hex, M10 x 1.25 x 20mm, Cl 10.9, Full Thd | LEC Superseded by part number: 15970531 |
| 21. | 79005063 | [4] | LEVER | LEC |
| 22. | 79011419 | [2] | BRAKE SHOE | LECBRAKE BAND - ASSEMBLY Superseded by part number: 79106501 |
| 23. | 79011420 | [10] | BRAKE LINING | LECSEGMENT Superseded by part number: 76047410 |
| 24. | 79011455 | [2] | ROD-TIP | LECPUSH ROD |
| 25. | 79087717 | [2] | LINK/SHACKLE | LECSCHACKLE |
| 26. | 79014027 | [2] | SCREW | LEC- ASSEMBLY Superseded by part number: 75214774 |
| 27. | 79071606 | [2] | LINK/SHACKLE | LECSCHACKLE |
| 28. | 79065799 | [2] | PIN,18mm OD x 46mm L | LEC |
| 29. | 79057000 | [2] | ROLLER | LEC |
