凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (6-30) - WIRE GUIDE AND ROLLER ASSEMBLIES (S.N. CFH0044501 THRU CFH0044902) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
762 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
111-360
|
[8] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 3/4", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 3/4", G5 Superseded by part number: 280430
|
| 2. |
231-5146
|
[8] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 3. |
413-540
|
[2] |
BOLT,Hex, 5/16" - 18 x 2-1/2", Gr 5
|
CAS
Superseded by part number: 72187202, 88346
|
| 4. |
232-5315
|
[6] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 5. |
700119426
|
[2] |
SUPPORT
|
CAS
- roller, left
|
| 6. |
700119427
|
[2] |
SUPPORT
|
CAS
- roller, right
|
| 7. |
700119432
|
[2] |
ROLLER
|
CAS
- wire
|
| 8. |
700119431
|
[2] |
SPACER
|
CAS
- roller
|
| 9. |
700119416
|
[2] |
GUIDE
|
CAS
- wire
|
| 10. |
100-11100
|
[2] |
SNAP RING,#100, Ext
|
CAS
Ring, Snap, #100, Ext Superseded by part number: 25121
|
| 11. |
700119405
|
[1] |
SUPPORT
|
CAS
- guide, right
|
| 12. |
700119411
|
[1] |
GUIDE
|
CAS
- wire, right
|
| 13. |
700119413
|
[2] |
ROLLER
|
CAS
- wire, 2" diameter
|
| 14. |
700119415
|
[2] |
SHIELD
|
CAS
- roller
|
| 15. |
700119410
|
[1] |
GUIDE
|
CAS
- wire, left
|
| 16. |
413-520
|
[6] |
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
|
CAS
5/16-18 X 1-1/4 C Superseded by part number: 87657
|
| 17. |
231-5145
|
[6] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 18. |
700119414
|
[6] |
SPACER
|
CAS
BUSHING
|
| 19. |
700119803
|
[2] |
ROLLER
|
CAS
- wire, 3" diameter
|
| 20. |
700119403
|
[1] |
SUPPORT
|
CAS
- guide, left
|
