凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (6-32) - WIRE GUIDE AND ROLLER ASSEMBLIES (S.N. CFH0044903 AND LATER) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
488 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700707700
|
[2] |
BALL BEARING,6.48 mm ID x 31.75 mm OD x 13.08 mm
|
CAS
BEARING Superseded by part number: 700737442
|
| 2. |
700124084
|
[1] |
SHIELD
|
CAS
- roller
|
| 3. |
700119414
|
[6] |
SPACER
|
CAS
BUSHING - spacer
|
| 4. |
700119413
|
[2] |
ROLLER
|
CAS
- wire
|
| 5. |
700124080
|
[1] |
SUPPORT
|
CAS
WA - left
|
| 6. |
700124079
|
[1] |
GUIDE
|
CAS
ASSEMBLY - left
|
| 7. |
700124086
|
[1] |
GUIDE
|
CAS
ASSEMBLY - right
|
| 8. |
413-520
|
[6] |
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
|
CAS
5/16-18 X 1-1/4 C Superseded by part number: 87657
|
| 9. |
232-5315
|
[6] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 10. |
51200165
|
[2] |
SCREW,Hex, 1/4"-20 x 1", G5
|
HFI
1/4-20 X 1 C
|
| 11. |
1703354
|
[2] |
NUT
|
IH
1/4-20 HFTLN GR/G
|
| 12. |
700124087
|
[1] |
SUPPORT
|
CAS
WA - right
|
| 13. |
700124090
|
[1] |
SHIELD
|
CAS
- roller, right
|
| 14. |
700119803
|
[2] |
ROLLER
|
CAS
- wire
|
| 15. |
700124091
|
[1] |
GUIDE
|
CAS
- wire, right
|
| 16. |
700124085
|
[1] |
GUIDE
|
CAS
- wire
|
