纽荷兰零件查询(FD14E) - CRAWLER DOZER (90.1650[001]) - AIR CLEANER DUST EJECTOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
267 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 11106634 | [1] | BOLT,Hex, M10 x 35mm, Cl 10.9, Full Thd | LECC2678 Hex, M10 x 35, 10.9, Full Thd Superseded by part number: 86624978 |
| 2. | 11701721 | [1] | NUT,M10, Cl 10 | LEC10x1,5x8 C2678 Superseded by part number: 17038131 |
| 3. | 14496631 | [2] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LECC2678 M10 x 21 x 2 Superseded by part number: 14496621 |
| 4. | 79082734 | [1] | CUP | LECC2678 |
| 5. | 79083845 | [2] | HOSE CLAMP,32mm - 50mm, Worm Gear | LECCOLLAR Superseded by part number: 71404506 |
| 6. | 79090123 | [1] | AIR PRE-CLEANER ASSY | LECAIR INTAKE C2678 Superseded by part number: 76031283, 71420328 |
| 7. | 79090193 | [1] | COWLING | LECHOOD C2678 Superseded by part number: 12626231, 79099224, 79093402 |
| 8. | 79090200 | [1] | EXTENSION | LECC2678 |
| 9. | 79090203 | [1] | HOSE | LEC |
| 10. | 79090224 | [1] | MUFFLER | LEC Superseded by part number: 79102770 |
| 11. | 79092237 | [1] | HOSE | LECSLEEVE C2678 |
| 12. | 79090242 | [1] | CLAMP,144mm ID | LECCOLLAR C2678 |
| 13. | 79090332 | [1] | AIR FILTER | LECDRY AIR CLEANER - ASSEMBLY SEE TAV.2 |
