凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (54) - BALE TENSIONER, HYDRAULIC, ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
560 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
755744
|
[2] |
CLAMP
|
CAS
Superseded by part number: 86594406
|
| 2. |
700108524
|
[1] |
SHIELD
|
HFI
|
| 3. |
7892128
|
[1] |
VALVE
|
CAS
GEAR PUMP ASSEMBLY
|
| 4. |
7046113
|
[1] |
TEE
|
CAS
Superseded by part number: 217-1063
|
| 5. |
046219
|
[1] |
BUSING - reducer
|
|
| 6. |
700703817
|
[1] |
GAUGE
|
CAS
- pressure
|
| 7. |
7746365
|
[1] |
ELBOW
|
CAS
- 90 degrees Superseded by part number: 235131
|
| 8. |
700703818
|
[1] |
HOSE ASSY.
|
HFI
HOSE - hydraulic
|
| 9. |
061747
|
[1] |
GIB KEY
|
|
| 10. |
700108526
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET - knotter drive
|
| 11. |
700703816
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET - pump drive
|
| 12. |
700115572
|
[1] |
SQ HOLE WASHER
|
CAS
SPACER
|
| 13. |
087973
|
[1] |
SPROCKET - idler
|
|
| 14. |
700703899
|
[1] |
CYLINDER
|
CAS
- hydraulic
|
| 15. |
7852148
|
[1] |
RING, SNAP
|
IH
SNAP RING
|
| 16. |
846170
|
[1] |
ELBOW
|
CAS
- 90 degrees Superseded by part number: 578384
|
| 17. |
700703825
|
[2] |
CLAMP
|
HFI
|
| . . |
7870181
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2 1/2", Gr 5
|
CAS
5/8-11 X 2-1/2 RHSNB Superseded by part number: 280742
|
| . . |
702035
|
[4] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 X 1-1/4 C
|
| . . |
7883341
|
[2] |
SCREW,Hex Washer, 5/16" - 18 x 1 1/4"
|
CAS
5/16-18 X 1-1/4 HWHMS Superseded by part number: 163-41
|
| . . |
7883333
|
[2] |
BOLT,Hex, 5/16" - 18 x 1", Gr 120M
|
CAS
5/16-18 X 1 HWHMS Superseded by part number: 121-108
|
| . . |
069765
|
[1] |
1/4-20 X 38 CPHSSS
|
|
| . . |
705632
|
[5] |
WASHER
|
CAS
5/8 NP Superseded by part number: 495-11066, 495-11066, 87365
|
