凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (56) - PUMP AND RESERVOIR, HYDRAULIC Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
279 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
7892128
|
[1] |
VALVE
|
CAS
HYDRAULIC PUMP AND RESERVOIR COMPLETE
|
| 1. |
063024
|
[1] |
SLOTTED SPRING PIN
|
|
| 2. |
8040552
|
[1] |
KNOB
|
CAS
|
| 3. |
8040545
|
[1] |
ROD
|
CAS
connector
|
| 4. |
8040560
|
[1] |
ADJUSTMENT SCREW
|
CAS
adjusting
|
| 5. |
8040578
|
[1] |
PLUG
|
CAS
ASSEMBLY (Includes o-ring)
|
| 6. |
8040503
|
[1] |
GUIDE
|
CAS
spring
|
| 7. |
8040495
|
[1] |
SPRING
|
CAS
|
| 8. |
730820
|
[1] |
SHIM
|
CAS
Superseded by part number: 64759
|
| 9. |
731679
|
[1] |
VALVE POPPET
|
CAS
POPPET ASSEMBLY Superseded by part number: H83931
|
| 10. |
7071871
|
[4] |
12 PT SCREW
|
HFI
CAP SCREW Superseded by part number: 166-11
|
| 11. |
8040537
|
[1] |
GEAR
|
CAS
IDLER GEAR ASSEMBLY Superseded by part number: 668389R91
|
| 12. |
730259
|
[1] |
GASKET
|
CAS
reservoir Superseded by part number: 668399R1
|
| 13. |
8040529
|
[1] |
GEAR
|
CAS
DRIVE GEAR ASSEMBLY Superseded by part number: 668388R91
|
| 14. |
8040487
|
[1] |
KEY
|
CAS
|
| 15. |
730804
|
[2] |
DOWEL,1/4" x 1/2"
|
CAS
PIN Superseded by part number: 37-148
|
| 16. |
731067
|
[1] |
LARGE PLATE
|
CAS
FRONT PLATE ASSEMBLY Superseded by part number: H646265
|
| 17. |
730275
|
[1] |
FILTER
|
CAS
SCREEN ASSEMBLY Superseded by part number: 668398R91
|
| 18. |
CAS2700072
|
[1] |
RESERVOIR, HYDRAULIC
|
CAS
RESERVOIR
|
| 19. |
2700073
|
[1] |
SPRING
|
CAS
Superseded by part number: 823148C1
|
| 20. |
733766
|
[1] |
FILTER
|
CAS
POCKET ASSEMBLY Superseded by part number: 668395R11
|
| 21. |
730895
|
[1] |
CAP
|
CAS
FILTER CAP Superseded by part number: 668396R1
|
| 22. |
733774
|
[1] |
COVER
|
CAS
LID AND GASKET Superseded by part number: 668393R11
|
| 23. |
730887
|
[1] |
FILTER
|
CAS
AIR FILTER Superseded by part number: 668400R1
|
| 24. |
040782
|
[1] |
BREATHER CAP
|
|
| 25. |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
|
| . . |
2700074
|
[3] |
12 PT SCREW,Flg, 5/16" - 18 x 5/8", Gr 8
|
CAS
5/16-18 X 5/8 C Superseded by part number: 166-23
|
| . . |
8040479
|
[1] |
LARGE PLATE
|
CAS
BACK PLATE REPAIR KIT, Includes items in art marked with asterisk.
|
| . . |
8040586
|
[1] |
SEAL KIT
|
CAS
SEAL REPAIR KIT, Includes items in art marked with (2) Asterisks. Superseded by part number: 200420C91
|
