凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (26) - PICKUP TINE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
971 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700108622
|
[8] |
FLANGED BEARING
|
L
FLANGE - bearing
|
| 2. |
700108609
|
[1] |
ROTOR
|
CAS
SHAFT - pickup
|
| 3. |
701367
|
[4] |
HEX SOC SCREW,3/8"-16 x 2 1/4"
|
CAS
SOCKET HEAD CAP SCREW Superseded by part number: 61-636
|
| 4. |
710392
|
[8] |
BEARING, ROLLER, CYL,27.33 mm ID x 47.09 mm OD x 25.4 mm
|
L
BEARING - spherical Superseded by part number: 84330047
|
| 5. |
700108618
|
[4] |
ARM
|
L
CRANK - tine bar
|
| 6. |
700705612
|
[4] |
CAM FOLLOWER
|
L
BEARING - cam Superseded by part number: 86536275
|
| 7. |
700707867
|
[4] |
NUT
|
CAS
1/2-20 HFTLN Superseded by part number: 87033645
|
| 8. |
700703860
|
[56] |
REEL TINE,Coiled, 2 Prongs, 164mm L
|
CAS
TINE - double
|
| 9. |
700108614
|
[4] |
CHANNEL
|
CAS
- tine
|
| . . |
700047
|
[56] |
BOLT
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| . . |
7700065
|
[16] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSNB Superseded by part number: 280430
|
| . . |
88902
|
[4] |
NUT,3/8"-16
|
NH
3/8-16 HCLN
|
