凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (28) - AUGER, RIGHT AND DRIVE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
706 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
051292
|
[3] |
BEARING - spherical
|
|
| 2. |
051417
|
[6] |
FLANGE - bearing
|
|
| 3. |
700704263
|
[1] |
SPHERICAL BEARING,55.562 mm ID x 100 mm OD x 48.4 mm
|
CAS
BEARING - spherical Superseded by part number: 76451
|
| 4. |
714360
|
[2] |
FLANGED BEARING
|
IH
FLANGE - spherical
|
| 5. |
700108630
|
[1] |
AUGER
|
CAS
- right
|
| 6. |
700108644
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET - double
|
| 7. |
061978
|
[1] |
KEY
|
CAS
GIB KEY
|
| 8. |
700108650
|
[1] |
PANEL
|
HFI
SHIELD - drive, right
|
| 9. |
6844344
|
[1] |
PIN
|
CAS
- hinge
|
| 10. |
700108658
|
[2] |
SUPPORT
|
CAS
- hinge Superseded by part number: 700163299
|
| 11. |
700108657
|
[1] |
SHIELD
|
HFI
- upper, right
|
| 12. |
061622
|
[1] |
GIB KEY
|
|
| 13. |
700108659
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET
|
| 14. |
7894967
|
[1] |
HANDLE
|
CAS
|
| 15. |
7758212
|
[1] |
SPRING
|
CAS
- fastener
|
| 16. |
7894975
|
[1] |
CLIP
|
CAS
|
| 17. |
063800
|
[2] |
PIN - dowel
|
|
| 18. |
058511
|
[4] |
SPRING - compression
|
|
| 19. |
700108669
|
[2] |
LARGE PLATE
|
CAS
SLUG
|
| 20. |
077016
|
[1] |
ZERK
|
|
| 21. |
069260
|
[1] |
1/2-13 X 1 CPSHSS
|
|
| 22. |
700108666
|
[1] |
HUB
|
CAS
- coupler
|
| 23. |
861203
|
[1] |
KEY
|
CAS
|
| 24. |
740233
|
[1] |
BUSHING
|
CAS
- oilite
|
| . . |
068619
|
[4] |
3/8-16 X 1-1/4 RHSNB
|
|
| . . |
700047
|
[6] |
BOLT
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| . . |
7700065
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSNB Superseded by part number: 280430
|
| . . |
7883325
|
[3] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 X 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
703132
|
[6] |
SERRATED SCREW
|
CAS
5/16-18 X 3/4 HFSS Superseded by part number: 145913
|
| . . |
413-58
|
[4] |
BOLT,Hex, 5/16" - 18 x 1/2", Gr 5
|
CAS
5/16-18 X 1/2 C Superseded by part number: 72187203, 88574
|
| . . |
705608
|
[1] |
WASHER,5/16", SAE
|
CAS
5/16 NP Superseded by part number: 495-11034
|
