纽荷兰零件查询(FD14E) - CRAWLER DOZER (0.0071[002]) - INTAKE MANIFOLD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
582 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4726704 | [1] | INTAKE MANIFOLD (ASSY) | |
| 2. | 4746085 | [2] | GASKET | MOD Superseded by part number: 4851440 |
| 3. | 4577310 | [1] | PLUG,1/2", Gas | JES Superseded by part number: 44903406 |
| 4. | 4753563 | [1] | PLUG,M10 x 1.5 | MOD |
| 5. | 10263360 | [1] | SEAL,20.3mm ID x 26mm OD x 1mm Thk | TTFWASHER, SEALING, , Copper M20.3 x 26 x 1 |
| 6. | 10276401 | [1] | PLUG | MKT Superseded by part number: 10305271 |
| 7. | 10264560 | [1] | SEAL,24mm ID x 32mm OD x 1.5mm Thk | TTFWASHER, SEALING, , Copper M24.4 x 32 x 1.5 |
| 8. | 10520001 | [4] | WASHER,12.2mm ID x 22mm OD x 3mm Thk | BHB Superseded by part number: 17095304 |
| 9. | 15541021 | [2] | SCREW,Hex, M12 x 1.25 x 60mm, Cl 8.8 | TTF(M 12x60) Superseded by part number: 15541024 |
| 10. | 15541621 | [2] | SCREW,Hex, M12 x 1.25 x 100mm, Cl 8.8 | TTFBOLT, Hex, M12 x 1.25 x 100, 8.8 Superseded by part number: 15541624 |
| 11. | 4858606 | [1] | SEAL,10.2mm ID x 16mm OD x 1mm Thk | TTFGASKET |
| 12. | 13543421 | [4] | STUD | MKT(M8 x 28) Superseded by part number: 13543424 |
| 13. | 13526170 | [1] | THREADED INSERT | TORTHREADED INSERT |
