| 1. |
700108677
|
[4] |
SPACER
|
HFI
Superseded by part number: 355682R1
|
| 2. |
700108424
|
[2] |
SUPPORT
|
HFI
- vertical
|
| 3. |
700108393
|
[2] |
CHANNEL
|
HFI
- chamber, side
|
| 4. |
6552558
|
[1] |
CHANNEL
|
CAS
- cross, lower
|
| 5. |
6560601
|
[1] |
ROD
|
HFI
- tension
|
| 6. |
700108394
|
[2] |
DOOR ASSY.
|
HFI
DOOR - side
|
| 7. |
700108422
|
[4] |
CLIP
|
HFI
- door
|
| 8. |
700108408
|
[2] |
PAD
|
HFI
- knife
|
| 9. |
700108409
|
[1] |
PAD
|
HFI
- knife - center
|
| 10. |
700108397
|
[2] |
PLATE
|
CAS
RESISTOR - plate, hay
|
| 11. |
837971
|
[4] |
CASTING
|
CAS
RESISTOR - bar, hay
|
| 12. |
700108406
|
[8] |
ADJUSTING PLATE
|
CAS
SHIM
|
| 13. |
700703779
|
[2] |
KNIFE
|
CAS
|
| 14. |
700108413
|
[2] |
PLATE
|
HFI
- filler
|
| 15. |
700108411
|
[1] |
PLATE
|
CAS
- right
|
| 16. |
700108412
|
[1] |
PLATE
|
CAS
- center
|
| 17. |
700108410
|
[1] |
PLATE
|
CAS
- left
|
| 18. |
700108414
|
[1] |
PLATE
|
HFI
- filler
|
| 19. |
700108401
|
[4] |
SUPPORT
|
CAS
SPREADER - tie
|
| 20. |
700108433
|
[1] |
SUPPORT
|
CAS
TRUSS
|
| 21. |
700108428
|
[2] |
RAIL
|
HFI
|
| 22. |
324269
|
[4] |
BUSHING
|
CAS
SPACER Superseded by part number: A28893
|
| 23. |
7020597
|
[1] |
BRACKET
|
CAS
STAKE - mounting, SMV (Extra)
|
| 24. |
7020589
|
[1] |
EMBLEM
|
CAS
- SMV (Extra) Superseded by part number: 86547710
|
| . . |
768226
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 X 1-3/4 RHSNB Superseded by part number: 88530
|
| . . |
7700156
|
[6] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420
|
| . . |
068619
|
[18] |
1/2-13 X 1-1/4 RHSNB
|
|
| . . |
7700131
|
[3] |
SHROUD,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 X 1 RHSNB Superseded by part number: 433-816, 433-816, NLS
|
| . . |
873406
|
[4] |
BOLT,Hex, 1/2" - 13 x 3", Gr 5, Full Thd
|
CAS
1/2-13 X 3 FTHCS Superseded by part number: 113-420
|
| . . |
707455
|
[4] |
BOLT,#3, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 X 1-3/4 PB Superseded by part number: 419-3828
|
| . . |
707018
|
[7] |
BOLT,#3, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
3/8-16 X 1-1/4 PB Superseded by part number: 118-140
|
| . . |
700047
|
[12] |
BOLT
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| . . |
7700065
|
[8] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSNB Superseded by part number: 280430
|
| . . |
703249
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
704288
|
[4] |
LOCK NUT
|
CAS
1/2-13 HCLN Superseded by part number: 230-4218
|
