凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (51) - PLUNGER STOP, SAFETY, ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
933 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
6247936
|
[1] |
SPACER
|
HFI
SPARER Superseded by part number: L57298
|
| 2. |
700703695
|
[1] |
STOP
|
HFI
CABLE - stop
|
| 3. |
700108637
|
[2] |
PLATE
|
HFI
|
| 4. |
700108575
|
[1] |
TUBE,25.4 mm OD, 910 mm Length
|
HFI
- cable
|
| 5. |
700108489
|
[1] |
PLATE
|
HFI
- rocker, stop
|
| 6. |
063685
|
[1] |
CLEVIS PIN
|
|
| 7. |
51200163
|
[1] |
CLEVIS
|
HFI
|
| 8. |
700108455
|
[3] |
LINK
|
HFI
|
| 9. |
758706
|
[1] |
COIL SPRING
|
CAS
SPRING - tension
|
| 10. |
700708272
|
[3] |
BUSHING
|
CAS
SPACER
|
| 11. |
700108488
|
[1] |
SHAFT
|
HFI
- plunger stop
|
| 12. |
27-8221
|
[1] |
CLEVIS PIN,1/2" x 2.218"
|
CAS
|
| . . |
701235
|
[3] |
BOLT,1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 C
|
| . . |
703983
|
[1] |
BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 X 1-3/4 C
|
| . . |
7701188
|
[1] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 C Superseded by part number: 87670
|
| . . |
703140
|
[4] |
BOLT,Hex, 1/4" - 20 x 1 3/4", Gr 5
|
CAS
1/4-20 X 1-3/4 C Superseded by part number: 413-428, 413-428, NLS
|
| . . |
704288
|
[1] |
LOCK NUT
|
CAS
1/2-13 HCLN Superseded by part number: 230-4218
|
| . . |
704197
|
[1] |
NUT
|
CAS
3/8-24 HJN Superseded by part number: 425-156, 425-156, NLS
|
| . . |
704742
|
[2] |
ROD
|
NNA
1/2-13 HFTLN Superseded by part number: 231-5348, 231-5348, 86516877
|
