凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (45) - STAR WHEEL AND SPACER CAM ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
619 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
063040
|
[1] |
SLOTTED SPRING PIN
|
|
| 2. |
700108471
|
[2] |
STRAP
|
CAS
- trip
|
| 3. |
6524938
|
[1] |
SPACER
|
CAS
Superseded by part number: 6823769
|
| 4. |
700108468
|
[1] |
ARM
|
CAS
- clutch
|
| 5. |
6530471
|
[2] |
RIM
|
CAS
SHIELD - wheel
|
| 6. |
2401516
|
[1] |
SPACER
|
CAS
- hub
|
| 7. |
700108475
|
[1] |
SUPPORT
|
HFI
- wheel, meter
|
| 8. |
700108478
|
[1] |
SHAFT
|
CAS
WHEEL - meter
|
| 9. |
077016
|
[1] |
ZERK
|
|
| 10. |
700108473
|
[1] |
CAM
|
IH
|
| 11. |
1661234
|
[1] |
CLAMP
|
IH
- stop
|
| . . |
7703499
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 X 3/4 C Superseded by part number: 87872
|
| . . |
703249
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
702035
|
[2] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 X 1-1/4 C
|
| . . |
230-4215
|
[2] |
NUT,5/16"-18, GA
|
CAS
5/16-18 HCLN
|
| . . |
88902
|
[1] |
NUT,3/8"-16
|
NH
3/8-16 HCLN
|
