| 1. |
6553317
|
[4] |
ADJUSTING PLATE
|
CAS
1-1/8 X 22 GAUGE MACHINERY BUSHING
|
| 2. |
6853592
|
[2] |
SLEEVE
|
CAS
- shear
|
| 3. |
700108438
|
[1] |
ARM ASSY.
|
HFI
ARM - drive, shear
|
| 4. |
700107076
|
[2] |
SHAFT
|
HFI
- knotter drive
|
| 5. |
6853659
|
[1] |
CAM
|
HFI
CLUTCH
|
| 6. |
063024
|
[1] |
SLOTTED SPRING PIN
|
|
| 7. |
6853642
|
[1] |
PIN
|
CAS
- dog
|
| 8. |
7758857
|
[1] |
SPRING
|
CAS
- torsion
|
| 9. |
6853626
|
[1] |
DRIVE DOG
|
CAS
DOG - cam
|
| 10. |
6853634
|
[1] |
ROLLER
|
CAS
|
| 11. |
762286
|
[1] |
PIN
|
CAS
- dowel Superseded by part number: 81844
|
| 12. |
7852171
|
[7] |
BUSHING
|
CAS
1-1/8 X 20 GAUGE MACHINERY BUSHING
|
| 13. |
6853857
|
[1] |
LUG
|
CAS
|
| 14. |
7852023
|
[2] |
BUSHING
|
CAS
- bronze
|
| 15. |
6853303
|
[1] |
PINION
|
L
SPROCKET ASSEMBLY (Includes bushings)
|
| 16. |
077040
|
[1] |
ZERK
|
|
| 17. |
050534
|
[2] |
FLANGE - bearing
|
|
| 18. |
700708095
|
[1] |
SPHERICAL BEARING
|
CAS
BEARING - spherical Superseded by part number: 47577195, 45876
|
| 19. |
6553283
|
[1] |
DISC
|
CAS
- brake
|
| 20. |
700703198
|
[3] |
WOODRUFF KEY,#28, 5/16" x 2 1/8"
|
CAS
KEY - Woodruff
|
| 21. |
700107077
|
[1] |
CAM
|
HFI
- knotter
|
| 22. |
7852189
|
[6] |
BUSHING
|
CAS
1-1/8 X 22 GAUGE MACHINERY BUSHING Superseded by part number: 195-2111
|
| 23. |
700706574
|
[1] |
BOLT
|
HFI
1-1/8 X 12 SLOTTED HEX JAM NUT
|
| 24. |
052522
|
[1] |
1-1/8 X 10 GAUGE MACHINERY BUSHING
|
|
| 25. |
6553291
|
[2] |
GEAR
|
HFI
- cam Superseded by part number: 700122623
|
| 26. |
6553325
|
[4] |
ADJUSTING PLATE
|
CAS
1-1/8 X .010 SHIM
|
| 27. |
6853899
|
[1] |
SPACER
|
CAS
|
| . . |
7703457
|
[3] |
HYD CONNECTOR,Hex, 1/4" - 20 x 3/4", Gr 5
|
NNA
1/4-20 X 3/4 C Superseded by part number: 413-412, 413-412, 86516954
|
| . . |
413-532
|
[1] |
BOLT,Hex, 5/16" - 18 x 2", Gr 5
|
CAS
5/16-18 X 2 C Superseded by part number: 9636711
|
| . . |
703199
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
|
CAS
3/8-16 X 3/4 C
|
| . . |
7701899
|
[2] |
BOLT,Hex, 3/8" - 16 x 2 1/2", Gr 5
|
CAS
3/8-16 X 2-1/2 C Superseded by part number: 87936
|
| . . |
069195
|
[1] |
3/8-16 X 1/2 CPSQHSS
|
|
| . . |
704163
|
[1] |
LOCK NUT
|
CAS
5/16-18 HTLN Superseded by part number: 230-4145
|
| . . |
704635
|
[2] |
NUT
|
CAS
3/8-16 HCLN Superseded by part number: 230-4216, 230-4216, 88902
|
| . . |
495-11053
|
[1] |
WASHER,1/2", SAE
|
CAS
1/2 NP Superseded by part number: 87364, 72187259
|
| . . |
705657
|
[1] |
WASHER
|
CAS
3/8 NP Superseded by part number: 495-11041, 495-11041, NLS
|
