700111998
|
[1] |
KNOTTER
|
HFI
HEAD COMPLETE (Equipped with (2) twine springs) Superseded by part number: 700124193, 706553259
|
| 1. |
8745358
|
[1] |
DISC
|
IH
- twine
|
| 2. |
6853352
|
[2] |
CLEANER
|
CAS
- knotter
|
| 3. |
63396
|
[1] |
LOCK PIN,3/16" x 1 1/2", Slotted
|
CAS
SLOTTED SPRING PIN Superseded by part number: 87020817
|
| 4. |
6858971
|
[1] |
BASE
|
CAS
- knife
|
| 5. |
49783
|
[1] |
KNIFE
|
CAS
- twine Superseded by part number: 700718710
|
| 6. |
6613624
|
[1] |
WASHER, LOCK
|
CAS
LOCK - tab
|
| 7. |
6853345
|
[1] |
STRIPPER
|
HFI
ARM - stripper
|
| 8. |
6591572
|
[1] |
WASHER
|
CAS
- special Superseded by part number: 87364
|
| 9. |
7852593
|
[2] |
SHIM,15mm ID x 21mm OD x 1mm Thk
|
CAS
MACHINERY BUSHING Superseded by part number: 84007145
|
| 10. |
700122799
|
[1] |
ROLLER
|
CAS
- spherical
|
| 11. |
7852577
|
[1] |
RING, SNAP
|
CAS
RING - retainer
|
| 12. |
6591580
|
[1] |
SHAFT
|
CAS
- stripper arm
|
| 13. |
863761
|
[3] |
PIN, GROOVED
|
CAS
GROOVE PIN Superseded by part number: 435-7614
|
| 14. |
7894389
|
[1] |
PINION
|
CAS
GEAR - pinion, bill hook
|
| 15. |
87415
|
[2] |
LUBE NIPPLE,90 Degree, 1/4" NPT x 3/4" L, Drive
|
NH
ZERK - 90 degrees
|
| 16. |
6853329
|
[1] |
FRAME
|
HFI
HEAD FRAME - knotter Superseded by part number: 7852742, 700122621, 700122619, 128359
|
| 17. |
6553267
|
[1] |
SHORT SHAFT
|
CAS
SHAFT - worm, knotter
|
| 18. |
7894421
|
[1] |
WORM
|
CAS
GEAR - pinion, worm
|
| 19. |
6523203
|
[1] |
CAM
|
CAS
- bill hook
|
| 20. |
138-153
|
[1] |
LOCK PIN,5/16" x 1", Slotted
|
CAS
SLOTTED SPRING PIN Superseded by part number: 88005
|
| 21. |
7895733
|
[1] |
SPRING
|
CAS
TENSIONER SPRING Superseded by part number: 9838781
|
| 22. |
6523229
|
[1] |
STUD
|
CAS
- mounting
|
| 23. |
77818
|
[4] |
FITTING
|
CAS
ZERK Superseded by part number: 87414
|
| 24. |
6553275
|
[1] |
SHIM
|
CAS
- countershaft
|
| 25. |
7852742
|
[1] |
WASHER,19.84mm ID x 27.38mm OD x 0.889mm Thk
|
CAS
MACHINERY BUSHING
|
| 26. |
852533
|
[1] |
OIL SEAL
|
CAS
RING - retainer Superseded by part number: 129164
|
| 27. |
6553259
|
[2] |
SPRING
|
CAS
- twine Superseded by part number: 706553259
|
| 28. |
7894454
|
[1] |
PINION
|
CAS
GEAR - twine disc
|
| 29. |
7894413
|
[1] |
WORM GEAR
|
CAS
GEAR - worm
|
| 30. |
700108195
|
[1] |
BILL HOOK
|
CAS
- knotter
|
| 31. |
7852163
|
[1] |
BUSHING
|
CAS
MACHINERY BUSHING
|
| 32. |
733048
|
[1] |
O-RING
|
CAS
O - RING Superseded by part number: 128359
|
| 33. |
8745325
|
[1] |
HOLDER
|
CAS
- twine
|
| 34. |
6523237
|
[1] |
SCREW
|
CAS
SHOULDER SCREW
|
| . . |
703249
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
231-1445
|
[1] |
NUT,5/16"-18, GB
|
CAS
5/16-18 REGULAR STOP NUT Superseded by part number: 86050277
|
