凯斯零件查询(8555) - CASE IH RECTANGULAR BALER (1/90-12/99) (02-08) - IMPLEMENT DRIVELINE ASSEMBLY (NEAPCO) (S.N. CFH0046873 AND LATER) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
923 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700713992
|
[1] |
JOINT
|
CAS
output half Superseded by part number: 700720666
|
| 2. |
700708995
|
[1] |
JOINT
|
CAS
input half Superseded by part number: 700720663
|
| 3. |
700704385
|
[1] |
YOKE
|
CAS
YOKE
|
| 4. |
133137C91
|
[2] |
KIT
|
IH
cross and bearing Superseded by part number: 84355343
|
| 5. |
700704382
|
[1] |
FORK
|
CAS
YOKE tube and sleeve
|
| 6. |
86636814
|
[1] |
LUBE NIPPLE,1/4"-28 x .52" lg
|
GI
Superseded by part number: 88775
|
| 7. |
700704377
|
[1] |
NYLON BEARING
|
CAS
Superseded by part number: 136418
|
| 8. |
700710864
|
[2] |
RING
|
CAS
retaining
|
| 9. |
700709021
|
[1] |
SHIELD
|
CAS
bell Superseded by part number: 700720665
|
| 10. |
700709017
|
[4] |
BEARING COVER
|
CAS
shield Superseded by part number: 700720667
|
| 11. |
700709020
|
[1] |
SHIELD
|
CAS
inner Superseded by part number: 700720665
|
| 12. |
700713993
|
[1] |
CLUTCH
|
CAS
ASSEMBLY, Includes: Ref. 19 and 23
|
| 13. |
700704383
|
[1] |
FORK
|
CAS
YOKE and SHAFT
|
| 14. |
700709016
|
[1] |
SHIELD
|
CAS
bell Superseded by part number: 700720667
|
| 15. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 16. |
700709018
|
[1] |
SHIELD
|
CAS
outer Superseded by part number: 700720667
|
| 17. |
700709023
|
[4] |
BEARING COVER
|
CAS
bearing Superseded by part number: 700720665
|
| 18. |
700713994
|
[1] |
PAWL
|
CAS
KIT, Includes: 1 ring retainer, 2 pawls, springs and thrust washers
|
| 19. |
700714045
|
[1] |
YOKE
|
CAS
UNIVERSAL JOINT YOKE repair, Includes: Ref. 20 - 22
|
| 20. |
376219R1
|
[1] |
SNAP RING,1.653, Int, #165
|
IH
Ring, Snap, 1.653", Int, #165 Superseded by part number: 183442
|
| 21. |
663625R91
|
[1] |
BALL BEARING
|
CAS
Superseded by part number: 84330089
|
| 22. |
7852114
|
[1] |
BUSHING,34.9mm ID x 38.1mm OD x 33.27mm L
|
CAS
|
| 23. |
700714046
|
[1] |
COLLAR
|
CAS
|
