| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 00. | 4514700 | [4] | CLIP;HOSE | |
| 01. | 4055312 | [1] | CLIP;BAND | |
| 03. | J011020 | [2] | BOLT;SEMS | |
| 03. | J271020 | [2] | BOLT;SEMS | TJ901020 |
| 03. | J271020 | [2] | BOLT;SEMS | TJ222010 |
| 05. | 4190266 | [2] | CLIP | |
| 09. | 9170023 | [2] | HOSE;FUEL | |
| 09A. | 4327293 | [1] | PROTECTOR | |
| 10. | 4327293 | [4] | PROTECTOR |
