凯斯零件查询(8555) - CASE IH RECTANGULAR BALER (1/90-12/99) (03-12) - WINDGUARD ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
486 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700108402
|
[1] |
GUARD
|
HFI
WIND, WA
|
| 2. |
700708272
|
[2] |
BUSHING
|
CAS
|
| 3. |
705541
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened, plain, 1/2
|
| 4. |
231-5348
|
[2] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
hex flange top lock, 1/2-13, GR/G Superseded by part number: 86521610
|
| 5. |
758441
|
[1] |
SPRING
|
IH
extension
|
| 6. |
413-824
|
[2] |
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 87689, 72187216
|
