凯斯零件查询(8555) - CASE IH RECTANGULAR BALER (1/90-12/99) (07-04) - WHEEL, HUB AND AXLE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
311 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
A38261
|
[2] |
VALVE
|
CAS
stem Superseded by part number: 196033
|
| 2. |
425-1312
|
[2] |
SLOTTED NUT,3/4"-16, G5
|
CAS
hex, 3/4-16 Superseded by part number: 88886
|
| 3. |
651818R91
|
[2] |
ROLLER BEARING,31.77 mm ID x 16.08 mm
|
IH
outer Superseded by part number: 84356153
|
| 4. |
T52730
|
[12] |
WHEEL BOLT
|
IH
wheel, 9/16-18 Superseded by part number: 86628557
|
| 5. |
826255
|
[2] |
HUB
|
CAS
ASSEMBLY, Includes: Ref. 9 and 10
|
| 6. |
700108335
|
[2] |
SPINDLE
|
CAS
WA
|
| 7. |
844050
|
[2] |
SEAL
|
L
|
| 8. |
663557R91
|
[2] |
BEARING ASSY,1.625" ID x 2.892" OD x 0.77"
|
IH
inner Superseded by part number: 86512015
|
| 9. |
663558R1
|
[2] |
BEARING CUP
|
IH
inner Superseded by part number: 86512015
|
| 10. |
651817R1
|
[2] |
BEARING CUP
|
IH
cup, outer Superseded by part number: 84356153
|
| 11. |
26971
|
[2] |
WASHER
|
CAS
|
| 12. |
432-1024
|
[2] |
COTTER PIN,5/32" x 1 1/2"
|
CAS
5/32" x 1 1/2" Superseded by part number: 72187233, 88350
|
| 13. |
518842R1
|
[2] |
CAP
|
IH
hub
|
| 14. |
A57879
|
[2] |
RIM
|
CAS
WHEEL standard 15", Includes: Ref. 1
|
| . . |
700707982
|
[2] |
RIM
|
CAS
WHEEL WHEEL high flotation 13.5", Includes: Ref. 1 Superseded by part number: 10110254
|
