| 1. |
700108531
|
[1] |
DOOR
|
HFI
|
| 2. |
700108541
|
[1] |
LID
|
CAS
twine box
|
| 3. |
413-440
|
[2] |
BOLT,Hex, 1/4" - 20 x 2-1/2", Gr 5
|
CAS
Superseded by part number: 87845
|
| 4. |
6549869
|
[1] |
SUPPORT
|
L
BRACKET tension
|
| 5. |
700108542
|
[1] |
SUPPORT
|
HFI
|
| 6. |
58925
|
[2] |
SPRING
|
CAS
|
| 7. |
231-1444
|
[2] |
NUT,1/4"-20, GB
|
CAS
Light hex stop Superseded by part number: 86625061
|
| 8. |
496-11028
|
[2] |
WASHER,9/32" x 5/8" x .065, HDN
|
CAS
hardened, plain, 1/4 Superseded by part number: 86632587
|
| 9. |
700108535
|
[2] |
SUPPORT
|
CAS
WA
|
| 10. |
256873
|
[2] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 11. |
231-5145
|
[13] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
Superseded by part number: 72187067, 145458
|
| 12. |
413-636
|
[2] |
BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 88546, 72187212
|
| 13. |
231-5146
|
[8] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 14. |
700136672
|
[1] |
BOX
|
HFI
twine
|
| 15. |
409-7612
|
[6] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 16. |
700707858
|
[2] |
SNAP RING
|
CAS
RING
|
| 17. |
700108570
|
[1] |
ROD
|
CAS
HINGE
|
| 18. |
700108566
|
[1] |
TOOL BOX
|
CAS
tool, WA
|
| 19. |
700108569
|
[1] |
LID
|
CAS
BOX tool
|
| 21. |
700108543
|
[2] |
SUPPORT
|
CAS
WA
|
| 22. |
403303
|
[2] |
TRACK CHAIN
|
HFI
SPACER
|
| 23. |
700108545
|
[1] |
SHIELD
|
HFI
left
|
| 24. |
409-7512
|
[6] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Superseded by part number: 145913, 72187186
|
| 25. |
700108573
|
[1] |
SHIELD
|
HFI
|
| 26. |
492-11038
|
[1] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 27. |
425-106
|
[1] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 28. |
121-115
|
[7] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 29. |
700121416
|
[1] |
ANGLE
|
HFI
left
|
| 30. |
700121092
|
[1] |
SHIELD
|
HFI
top, WA
|
| 31. |
700108532
|
[1] |
SUPPORT
|
HFI
WA
|
| 32. |
496-21034
|
[1] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 33. |
7758212
|
[1] |
SPRING
|
CAS
compression
|
| 34. |
7894975
|
[1] |
CLIP
|
CAS
fastener
|
| 35. |
7894967
|
[1] |
HANDLE
|
CAS
fastener
|
| 36. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
hardened, plain, 3/8 Superseded by part number: 86632588
|
