神钢零件查询(F4HFE613D B006) - ENGINE 5801925168 47748447 TC 5.90 TIER 4B & TC5.90 hillside TIER 4B (1/12-) (10.106.AO[01]) - ROCKER ARM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
762 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2859460 | [6] | ROCKER ARM | TORASSY, Incl 2 - 13 |
| 2. | 4898717 | [2] | ROCKER ARM | TOR Superseded by part number: 504344540 |
| 3. | 2859464 | [2] | RETAINER,10.79mm ID, 7.63mm ID | TOR Superseded by part number: |
| 3. | 4897248 | [2] | RETAINER | TOR Superseded by part number: |
| 4. | 4897245 | [2] | SOCKET | TOR Superseded by part number: |
| 5. | 4895067 | [1] | ROCKER ARM | TORASSY, Incl 3, 4, 7 - 10 Superseded by part number: |
| 6. | 2859463 | [1] | SUPPORT | TOR Superseded by part number: |
| 6. | 4893487 | [1] | LEVER | TOR Superseded by part number: |
| 7. | 2859467 | [2] | NUT,Hex, 3/8" - 24, RH | TOR Superseded by part number: |
| 7. | 4895198 | [2] | NUT,3/8"-24, Heavy | LEC Superseded by part number: |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONArm, Incl in 5 |
| 9. | 2859468 | [2] | ADJUSTMENT SCREW,3/8" - 24 x 23.85mm | TOR Superseded by part number: |
| 10. | 2859470 | [2] | SOCKET | TOR |
| 11. | 2856460 | [2] | BOLT,Flng, M8 x 1.25 x 55.5mm, Cl 10.9 | TOR |
| 11. | 4899083 | [2] | SCREW | LEC53mm |
| 11. | 2830434 | [2] | SCREW | TOR55mm Superseded by part number: 4899083 |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONArm, Incl in 13 |
| 13. | 2859462 | [1] | ROCKER ARM | TORASSY, Incl 3, 4, 7, 9, 10, 12 |
| 13. | 4895068 | [1] | ROCKER ARM | TOR Superseded by part number: |
| 14. | 4895031 | [12] | PUSH ROD | TOR |
