纽荷兰零件查询(FD14E) - CRAWLER DOZER (3.4370[002]) - CONTROL VALVE LINKAGE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1002 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79092887 | [1] | HUB | LEC |
| 2. | 79084568 | [2] | BEARING ASSY,Needle, 16mm ID x 22mm OD x 14mm W | LECBUSHING |
| 3. | 79078172 | [1] | YOKE | LEC- ASSEMBLY |
| 4. | 79083329 | [1] | YOKE | LEC |
| 5. | 79084006 | [1] | ROD | LEC |
| 6. | 79090389 | [1] | TIE-ROD | LECTIEROD |
| 7. | 79078173 | [1] | PIN,16mm OD x 82mm L | LEC |
| 8. | 79078174 | [1] | PIN | LEC |
| 9. | 79081248 | [1] | BOOT | LECOUST BOOT |
| 10. | 79081280 | [1] | CAPPING | LECBEZEL |
| 11. | 13313417 | [4] | SCREW,Pozidriv Oval Hd, Csk, M6 x 25mm, Cl 5.8, Full Thd | IMO |
| 12. | 79090157 | [1] | HANDLE | LEC |
| 13. | 79090158 | [1] | BUSHING | LEC |
| 14. | 14164070 | [1] | LOCK PIN,M4 x 22, Slotted | MKTSPRING PIN 4,4x22 Superseded by part number: 14164071 |
| 15. | 14164370 | [2] | LOCK PIN,M4 x 30, Slotted | FORSPRING PIN 4,4x30 |
| 16. | 11702921 | [1] | NUT,M12, Cl 10 | LEC Superseded by part number: 17038425 |
| 17. | 79077337 | [1] | HANDLE GRIP | TORHANDGRIP Superseded by part number: 151615493 |
| 18. | 14496631 | [3] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 19. | 11106431 | [3] | SCREW,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LECSCREW 10x1,5x30 Superseded by part number: 9515003 |
