神钢零件查询(F4HFE613D B006) - ENGINE 5801925168 47748447 TC 5.90 TIER 4B & TC5.90 hillside TIER 4B (1/12-) (10.218.AI[02]) - FUEL LINE, PIPE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
622 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2855336 | [1] | RETURN PIPE | TOR Superseded by part number: |
| 1. | 504116745 | [1] | TUBE | TUBE |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONTube, Incl in 1 |
| 3. | 4894095 | [3] | O-RING,2.5mm Thk x 8mm ID, 60 Duro | TOR |
| 6. | 4896996 | [1] | CLAMP,8mm D Clamping pipes | TOR |
| 7. | 2852100 | [1] | FLANGE BOLT,Hex, M8 x 1.25 x 16mm | TOR Superseded by part number: 16586225 |
