凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (3-12) - PICKUP SLIP CLUTCH ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
221 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
873174
|
[6] |
BOLT,Hex, 3/8" - 16 x 3 1/4", Gr 5
|
CAS
3/8-16 X 3-1/4 C
|
| 2. |
700709603
|
[6] |
WASHER,3/8"
|
CAS
3/8 WIDE PLAIN WASHER Superseded by part number: 80702
|
| 3. |
74781
|
[6] |
NUT
|
CAS
3/8-16 LHSN Superseded by part number: 231-1406, 231-1406, NS
|
| 4. |
392464
|
[1] |
LARGE PLATE
|
CAS
PLATE - PRESSURE
|
| 5. |
700711025
|
[2] |
CLUTCH PLATE,92mm ID x 161.92mm OD x 3.18mm Thk
|
CAS
DISC - FRICTION
|
| 6. |
700108665
|
[1] |
CLUTCH ASSEMBLY
|
CAS
(Includes Item 11)
|
| 7. |
700108661
|
[1] |
PLATE
|
CAS
WA - CLUTCH
|
| 8. |
700123770
|
[1] |
SHAFT
|
CAS
|
| 9. |
61622
|
[1] |
BUCKET TOOTH KEY
|
IH
1/4 X 1-1/2 GIB KEY Superseded by part number: Q3914
|
| 10. |
58107
|
[6] |
SPRING
|
IH
- COMPRESSION
|
| 11. |
852749
|
[1] |
BRONZE BUSHING
|
CAS
BUSHING - BRONZE
|
