凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (3-14) - PICKUP ROTOR ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
223 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700108609
|
[1] |
ROTOR
|
CAS
WA
|
| 2. |
7700065
|
[16] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSNB Superseded by part number: 280430
|
| 3. |
705038
|
[16] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| 4. |
704023
|
[16] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| 5. |
701367
|
[4] |
HEX SOC SCREW,3/8"-16 x 2 1/4"
|
CAS
3/8-16 X 2-1/4 HSHCS SPL Superseded by part number: 61-636
|
| 6. |
704734
|
[56] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 7. |
710392
|
[8] |
BEARING, ROLLER, CYL,27.33 mm ID x 47.09 mm OD x 25.4 mm
|
L
BEARING - CYLINDRICAL Superseded by part number: 84330047
|
| 8. |
700108618
|
[4] |
ARM
|
L
CRANK WA
|
| 9. |
700705612
|
[4] |
CAM FOLLOWER
|
L
BEARING - CAM, FOLLOWER Superseded by part number: 86536275
|
| 10. |
700707867
|
[4] |
NUT
|
CAS
1/2-20 HFTLN GR/G Superseded by part number: 87033645
|
| 11. |
700123867
|
[4] |
ANGLE
|
CAS
WA
|
| 12. |
700709760
|
[52] |
TINE
|
L
TINE - DOUBLE
|
| 13. |
62307
|
[8] |
PIN
|
CAS
1/4 X 2 COTTER PIN Superseded by part number: 432-1632, 432-1632, NLS
|
| 14. |
700108622
|
[8] |
FLANGED BEARING
|
L
FLANGE - BEARING
|
| 15. |
700047
|
[52] |
BOLT
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 16. |
80702
|
[52] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
3/8 HARDENED PLAIN WASHER
|
